  • DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI TOUCH INTERACTIVE SMARTBOARD
DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI TOUCH INTERACTIVE SMARTBOARD
DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI TOUCH INTERACTIVE SMARTBOARD-cover-thumbnail DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI TOUCH INTERACTIVE SMARTBOARD-1

DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI TOUCH INTERACTIVE SMARTBOARD

Stock : Discontinued
PID : P00025064495
SKU : DOPAH-ILD-107
Brand : OTHERS
Model : ILD-107
★ ★ ★ ★ ★
0 Reviews
  • Both Side 20 hotkeys
  • 4k High-Definition Display
  • Proposition 10 Interfaces
  • Built-in WIFI access

    • DOPAH ILD-1075

    Display

    Model & SizeDopah ILD-1075 75''
    Display Ration16:9
    Brightness410cd/m2
    Contrast Ratio1400:1
    BacklightLED
    View Angle178° (V)/178° (H)
    Resolution3840(H) * 2160(V)
    Video StandardPAL/SECAM
    Audio Power2*15W
    TV Main Board

    Input Interfere

    • SD Card: 1
    • Multimedia USB: 2
    • HDMI: 2
    • USB30: 2
    • RF (TV): 1
    • VGA: 1
    • VGA Audio: 1
    • YPbPr(MINI): 1
    • AV (MINI): 1
    • RJ45: 1
    • RS232: 1

    Output Interface

    • USB Touch: 1
    • Earphone Output: 1
    • AV OUT (MINI): 1
    • Coaxial Output (Orange): 1

    Centralized Control Port

    • LAN: 3
    • WAN: 1
    • WIFI: 2.4G
    • USB3.0 (PC): 3
    • Display Port: 1
    • Reset: 1
    • Debug: 1

    Preposition Interface

    • USB2.0 (PC): 4
    • HDMI: 1
    • USB Touch: 1
    • Multimedia USB: 1
    • VGA IN: 1
    • VGA Audio IN: 1
    • MIC IN: 1
    Port Configuration

    Top PortUSB3.0 * 4, Campus radio * 1
    USB Play Format

    Support Video Play: MPEG1, MPEG2,MPEG,H264,RM,RMVB,MOV,MJPEG,VC1,Divx,FLV;

    Audio: MP3, WMA, AAC; PIC: JPG, BMP, PNG

    Campus RadioSupport RCA campus radio, and set campus broadcast channel as a priority
    Centralized Control SystemSupport Remote Power ON/OFF, unified Switching signal Channel, text push, picture push, ringing function etc.
    Wireless RouterBuild-in automatic WIFI hotspot
    Hot KeyBoth Side 20 hotkeys
    Preposition key9 keys (7 for TV, 1 for PC, 1 for energy saving), One Key turn on TV and PC; can switch TV separately; a key switch backlight energy-saving when PC is ON;
    OPS Module

    Main Board ModelH61/H81 (Optional)
    MemoryDDR3 1333 2G/4G/8G (Optional)
    Operating SystemWindows 10
    Sound CardIntegration
    WIFIOptional
    USB2.04
    Earphone Output1
    VGA OUT1
    RJ451
    CPUI3/I5/I7 (Optional)
    Hard Disk500G HDD/128G SSD/ 256G SSD (Optional)
    Graphics CardIntegration
    Wireless Mouse/KeyPadOptional
    BluetoothExtensible
    USB3.02
    MIC1
    HDMI
    		1
    Touch Screen

    Touch TechnologyMultiple infrared Scanning Technology
    Multi-touch10 touchpoints
    Touch Embedding MethodPreposition embedded (front maintenance)
    Touch and Drive MethodHID free drive
    Writing Surface Material4MM tempered glass (anti-glare is optional)
    Induction MethodFinger, writing pen, gloved hand or any other non-transparent touch-sensitive media
    Positioning Resolution4096*4096
    System Communication PortUSD2.0
    Sampling Rate>=120Hz
    Cursor SpeedMax. 300 dots/Second
    Coordinate Output32768(W) * 32768(D)
    Positioning Accuracy<=+-2mm
    Touch TimesMore than 60 million times
    CalibrationCalibration-Free

    Anti-Interference

    		Incandescent lamp (220V, 100W), vertical distance above 350mm the illumination of sunlight 90000Lux
    Measuring Ability Software detection can test equipment
    Remote Upgrade FunctionRemote Touch Hardware Control Program (MCU) Upgrade
    Power SupplyUSB 5.0V direct Supply

    DOPAH ILD-1075 75 INCH LED ALL-IN-ONE MULTI-TOUCH INTERACTIVE SMARTBOARD in Bangladesh

    Dopah ILD-1075 all-in-one multi-touch interactive smartboard has an LED display, the latest interactive flat panel technology, 75 inch flat panel allows you to show any content on the screen in a 4K 3840 x 2160 resolution and 350 nits of brightness, 10 point multi-touch screen allows you to control and annotate over any application that is running on a PC, MAC or Chrome OS directly from the screen, can use gestures to control applications.
