OVERVIEW
Model
| WR1300
|
Processor
| Dual-Core CPU
|
Flash
| 16MB
|
DDR
| 128MB
|
Antenna
| 4× Fixed Omni-Directional Antennas
|
Interface
| 1× 1000/100/10 Mbps WAN Port 4× 1000/100/10 Mbps LAN Ports
|
|
|
Button
| WPS Button, Reset Button
|
External Power Supply
| 12 V / 1 A
|
| Dimensions ( W x D x H ) | 204.8 x 137. 5 x 38. 3mm |
| Wireless Standards | IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GH
|
| Frequency | 5 GHz, 2.4 GHz
|
Signal Rate
| 867 Mbps (5 GHz), 300 Mbps (2.4 GHz)
Compatible with 802.11a/b/g/n/ac Wi-Fi standards
|
| Wireless Modes | Enable/Disable Wireless Radio, WMM WEP, WPA/WPA2,
|
| Wireless Functions | WPA-PSK/WPA2-PSK |
| WAN Type | Dynamic IP/Static IP/PPPoE |
| Package Contents | AC1200 Wi-Fi Router Power Adapter RJ45 Ethernet Cable Quick Installation Guide
|
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, Subscription with an internet service provider (for internet access)
|
| Warrenty | 1 year |
Concurrent Dual Band WiFi
2.4GHz provides extremely long range, 5GHz reaches 867Mbps, ideal for gaming and 4K streaming.Simple tasks like web browsing can be handled by the 2.4GHz band, while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band at the same time.
2-IN-1 WiFi Router / Access Point
When working in router mode, it can quickly establish a connection with the Internet through dial-up, so that all devices connected to it can enjoy high-speed networks.
When working in the access point mode, usually a modem or router is required in front of it to dial and play the role of DHCP server, it only undertakes the role of data forwarding.
High Performance CPU and Antennas
Powerful Dual-Core CPU ensures smooth 4K UHD streaming to Smart TVs, mobile devices and gaming consoles without buffering.
4x5dBi High gain antennas boost sensitivity of the WiFi router, create connections over greater distances, providing powerful penetration through walls.
Built-in VPN Clients
With built-in PPTP / L2TP VPN Clients, this router can easily establish a connection to VPN Server to transport all your online data and traffic, securing it with its encryption at the same time. You can use this function to connect your home network with your work network or school network. You only need to configure the router once, and all the devices in the network can be connected. Greatly facilitate your work, study and life.
20+ DDNS Support
When you apply for an Internet package from an operator, the operator will usually assign you an IP at random. A random and frequently changing IP cannot be used to remotely manage home networks and equipment. You can bind your home IP address to a custom domain name through the DDNS function. No matter how the IP changes, the domain name can point to your network, which makes remote management possible.
OpenWrt Ready
16MB Flash and 128MB DDR3 ensure the continuous operation of the operating system, makes the router runs faster and provides more possibilities for function expansion. And as bing built with such large flash and DDR, WR1300 makes it possible to install OpenWrt system. You can get related software from Cudy official website.
