Hikvision DS-7208HGHI-F2 08 Channel DVR
>Model- DS-7208HGHI-F2
>Video Input channel(BNC)- 8-ch BNC interface (1.0Vp-p, 75 Ω)
>Video compression- H.264
>Video output(VGA)- 1920 x 1080 / 60 Hz,1280 x 1024 / 60 Hz, 1280 x 720 / 60 Hz, 1024 x 768 / 60 Hz
>Video output(HDMI)- 1920 x 1080 / 60 Hz,1280 x 1024 / 60 Hz, 1280 x 720 / 60 Hz, 1024 x 768 / 60 Hz
>Audio Input channel RCA- RCA (2.0 Vp-p, 1 kΩ)
>Audio output channel- 1-ch RCA(Linear, 1kΩ)
>Two way audio- 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)
>Video recording res- 720p
>Frame rate- 1/16 fps ~ Real time frame rate
>Stream type- Video/Video&Audio
>Dual stream support- Support
>Number HDD interface(SATA)- 2 x SATA Interfaces
>Max HDD support(GB TB)- Up to 6 TB capacity for each disk
>Network interface(RJ45)- 1 x 10M / 100M self-adaptive Ethernet interface
>USB Port- 2 x USB 2.0 Interfaces
>PTZ controller- 4494949
>Warranty- 1 Year
Product Details
Hikvision DS-7208HGHI-F2 08 Channel DVR, Type - TVI DVR, Video Input Channel (BNC) - 8-ch BNC interface (1.0Vp-p, 75 Ω), Video Compression - H.264, Video Output (VGA) - 1920 x 1080 / 60 Hz,1280 x 1024 / 60 Hz, 1280 x 720 / 60 Hz, 1024 x 768 / 60 Hz, Video Output (HDMI) - 1920 x 1080 / 60 Hz,1280 x 1024 / 60 Hz, 1280 x 720 / 60 Hz, 1024 x 768 / 60 Hz, Audio Input Channel (RCA) - RCA (2.0 Vp-p, 1 kΩ), Audio Compression - G.711u, Audio Output Channel - 1-ch RCA(Linear, 1kΩ), Two way Audio - 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input), Video Recording Res. - 720p, Frame Rate - 1/16 fps ~ Real time frame rate, Stream Type - Video/Video&Audio, Dual Stream Support - Support, Number HDD interface (SATA) - 2 x SATA Interfaces, Max HDD Support(GB,TB) - Up to 6 TB capacity for each disk, Network Interface (RJ45) - 1; 10M / 100M self-adaptive Ethernet interface, USB Port - 2 x USB 2.0 Interfaces, Dimension - 380 x 290 x 48mm, Powr Supply - 12V DC, IP Video Input: 2-ch Up to 2MP resolution, Recording resolution: Main stream: 720P / WD1 / 4CIF / VGA / CIF ;Sub-stream: 4CIF (non-real-time) / 2CIF (non-real-time) / CIF, Video Bit Rate: 32Kbps - 4Mbps, Audio Bit Rate: 64kbps,Power supply- 12V DC, Weight- ≤ 1.2 Kg (2.6 lb) Warranty - 1 year.
