ASUS ROG STRIX Z890-E GAMING WIFI LGA1851 Intel Motherboard
- Intel Socket LGA1851
- Chipset Intel Z890 Chipset
- 4 x DIMM slots
- Wi-Fi 7 | Bluetooth v5.4
Product Pricing
EMI Start From*
SPECIFICATIONS
Processor
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to https://www.asus.com/support/download-center/ for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support
depends on the CPU types.
Mainboard
Memory
Support up to 8800+MT/s (OC), Non-ECC, Clocked
Unbuffered DIMM (CUDIMM)*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
memory module
Supports DIMM Flex
NitroPath DRAM Technology
DIMM Fit
ASUS Enhanced Memory Profile III (AEMP III)
Graphics
1 x HDMI® port***
2 x Intel® Thunderbolt 4 support DisplayPort and Thunderbolt™ video outputs
Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
Supports max. 8K@60Hz as specified in DisplayPort 1.4.
Supports max. 8K@60Hz as specified in HDMI 2.1.
In ThunderboltTM 4 mode, supports up to 8K@60Hz x1 with DSC or 4K@60Hz x 2, maximum total bandwidth up
to 23.8Gbps or 16Gbps/16Gbps, for resolution
support please check DisplayPort 2.1 specs.
In DP alt mode, Only one USB Type-C® port supports up to UHBR20 at a time.
VGA resolution support depends on processors' or graphic cards' resolution.
While installing the operating system, please ensure
that your monitor is connected to the HDMI
port on the back I/O panel or to a discrete graphics card.
Networking & Connectivity
ASUS LANGuard
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate.
Ports
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
5 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage related
7 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C®)
2 x USB 5Gbps headers support additional 4 USB 5Gbps ports
3 x USB 2.0 headers support additional 6 USB 2.0 ports
Miscellaneous
3 x Addressable Gen2 headers
1 x Chassis Intrusion header
1 x CPU Over Voltage jumper
1 x FlexKey button
1 x Front Panel Audio header (F_AUDIO)
1 x Start button
1 x 10-1 pin System Panel header
1 x Thermal Sensor header
1 x Thunderbolt™ (USB4®) header
9 x USB 10Gbps ports (7 x Type-A + 1 x USB Type-C® + 1 x
USB Type-C® with up to 30W PD Fast-charge)
3 x USB 5Gbps ports (3 x Type-A)
1 x DisplayPort
1 x HDMI® port
1 x Wi-Fi Module
1 x Realtek 5Gb Ethernet
2 x Gold-plated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
1 x Clear CMOS button
2 x Thunderbolt™ 4 (2 x USB Type-C®)
9 x USB 10Gbps ports (7 x Type-A + 1 x USB Type-C®* + 1
x USB Type-C® with up to 30W PD Fast-charge)
3 x USB 5Gbps ports (3 x Type-A)
Front USB (Total 11 ports)
1 x USB 20Gbps connector (supports USB Type-C®)
2 x USB 5Gbps headers support additional 4 USB 5Gbps ports
3 x USB 2.0 headers support additional 6 USB 2.0 ports
* USB Type-C® power delivery output: 5V/3A
** USB Type-C® power delivery output: 5V/9V max. 3A,
12V max 2.5A, 15V max. 2A.
Physical Specification
Warranty Information
DESCRIPTION
ASUS ROG Strix Z890-E Gaming WiFi LGA1851 Intel Motherboard
Dominate the high-end gaming and enthusiast PC space with the ASUS ROG Strix Z890-E Gaming WiFi. Engineered for the next generation of Intel Core Ultra Processors (Series 2) utilizing the LGA1851 socket, this flagship motherboard blends aggressive aesthetics with zero-compromise hardware. Whether you are building an elite gaming rig, a heavy-duty workstation, or a top-tier overclocking system, the Z890-E delivers unmatched power delivery, thermal management, and cutting-edge AI features like AI Overclocking and AI Cooling II.
Extreme DDR5 and Massive Storage Capacity
Push your system memory to unprecedented limits. The Z890-E features exclusive NitroPath DRAM Technology and AEMP III, allowing enthusiasts to drive up to 256GB of DDR5 memory to speeds exceeding 9200+ MT/s. For storage, it offers an astonishing seven M.2 slots on a single board. This includes three ultra-fast PCIe 5.0 NVMe SSD slots, allowing you to load massive game libraries, operating systems, and heavy project files with zero latency.
Robust Power Delivery and Elite Cooling
To handle the extreme demands of high-core-count Intel Core Ultra processors, the Z890-E is built with a heavy-duty 18+1+2+2 power stage design, with each stage rated to handle up to 110 amps. This ensures perfectly stable, undistorted power delivery under heavy loads. To keep thermals in check, it utilizes a massive VRM heatsink array, a dedicated M.2 combo-sink, and high-conductivity thermal pads, ensuring both the processor and your high-speed SSDs remain cool without throttling.
Next-Gen Connectivity and Studio-Grade Audio
Experience the fastest networking available. The motherboard features integrated Wi-Fi 7 (802.11be), allowing for 320MHz bandwidth and speeds up to 4.8X faster than standard Wi-Fi 6. For wired connections, it includes a robust Realtek 5Gb Ethernet port. Two onboard Thunderbolt 4 USB Type-C ports provide 40 Gbps bidirectional bandwidth for the latest external devices and 4K displays. Audio is powered by the SupremeFX ALC4080 Codec with a Savitech amplifier, delivering crystal-clear 120 dB SNR playback for perfect spatial awareness in competitive games.
PC DIY Made Effortless
ASUS makes building and upgrading your system incredibly simple. The revolutionary PCIe Slot Q-Release Slim allows you to unlock and remove your heavy modern graphics card by simply tilting it toward the latching mechanism—no buttons or hard-to-reach tabs required. Combined with M.2 Q-Release, M.2 Q-Slide, a pre-mounted I/O shield, and an onboard BIOS FlashBack button, assembling your dream machine has never been smoother.
Why Buy ASUS ROG Strix Z890-E Gaming WiFi Motherboard from Tech Land BD?
Tech Land BD, we specialize in high-end enthusiast PC hardware and custom builds. Buying the ASUS ROG Strix Z890-E from us guarantees a 100% authentic product backed by an official brand warranty. We provide the latest components, expert technical advice, and premium after-sales support to help you construct the ultimate Intel Core Ultra-powered system.
