GIGABYTE B550M AORUS PRO AX SOCKET AM4 DDR4 MOTHERBOARD
GIGABYTE B550M AORUS PRO AX SOCKET AM4 DDR4 MOTHERBOARD
GIGABYTE B550M AORUS PRO AX SOCKET AM4 DDR4 MOTHERBOARD - 0
GIGABYTE B550M AORUS PRO AX SOCKET AM4 DDR4 MOTHERBOARD - 1

GIGABYTE B550M AORUS PRO AX SOCKET AM4 DDR4 MOTHERBOARD

0 Reviews
Stock : Out of Stock
PID : P0392506204
Brand : Gigabyte
Model : B550M AORUS PRO AX
Warranty : 3 years
  • Supported CPU: AMD Socket AM4, support for: AMD Ryzen™ 5000 Series
  • Memory: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
  • LAN: Realtek® 2.5 GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
  • WiFi: WIFI a, b, g, n, ac, and ax, supporting 2.4/5 GHz Dual-Band

Product Pricing

Discount Price

৳18,600 ৳19,000
+ Available Payment Method

EMI Start From*

৳655

SPECIFICATIONS

Processor

Supported CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors

Mainboard

Chipset AMD B550
BIOS 1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
ECC memory (ECC mode) support varies by CPU
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules

Graphics

Graphics 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Support for HDMI 2.1 version, HDCP 2.3, and HDR.
1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.

Networking & Connectivity

LAN Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
WiFi WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band

Audio & Microphone

Audio Realtek® ALC1200 codec

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

Ports

Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen™ 5000 Series and Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode
AMD Ryzen™ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series Processors support PCIe 3.0 x16 mode
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:
Supporting PCIe 3.0 x2 mode
1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:
Supporting PCIe 3.0 x1 mode
Internal I/O Ports 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x water cooling CPU fan header

3 x system fan headers

2 x addressable LED strip headers

2 x RGB LED strip headers

1 x CPU cooler LED strip/RGB LED strip header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C® header, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x serial port header

1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-
TPM2.0_S module only)

1 x Clear CMOS jumper

Physical Specification

Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

Warranty Information

Warranty 3 years

DESCRIPTION

GIGABYTE B550M AORUS PRO AX SOCKET MOTHERBOARD in Bangladesh

AMD B550 AORUS Motherboard with 10+2 Phases Digital Twin Power Design, Enlarged Surface Heatsinks, PCIe 4.0 x16 Slot, Dual PCIe 4.0/3.0 x4 M.2, 2.5GbE LAN, Intel® WiFi 6 802.11ax, Rear & Front USB Type-C®, RGB FUSION 2.0, Q-Flash Plus. GIGABYTE B550 motherboards maximize your PC's potential with AMD StoreMI technology. StoreMI accelerates traditional storage devices to reduce boot times and enhance the overall user experience. This easy-to-use utility combines the speed of SSDs with the high capacity of HDDs into a single drive, enhances the read/write speeds of the device to match that of SSDs, bolsters data performance for incredible value, and transforms the everyday PC into a performance-driven system.

ULTIMATE POWER DESIGN

To fully support the latest 3rd Gen AMD Ryzen™ processors, B550 AORUS motherboards are equipped with the ultimate power solution, which is power-balanced, digital, and multi-phase. After countless experiments and testing, GIGABYTE presents the unbeatable B550 AORUS motherboards for enthusiasts. No compromise, and never stop to achieve more.

UNPARALLELED PERFORMANCE
GIGABYTE realizes that customers won't stop chasing better computing performance. We take care of it and implement it on products. Adopting Daisy Chain, apply PCIe 4.0 components to get B550 motherboards ready to enter the next generation and get an upgrade.
ADVANCED THERMAL SOLUTION
Unthrottled performance is guaranteed by the advanced thermal solution which including Heatsinks and thermal guards. B550 motherboards are cool on MOSFETs and M.2 SSDs even on full load. It provides lower temperatures for users.
HI-FI AUDIO SYSTEM
For enthusiasts, sound quality is just as essential to the gaming experience. B550 motherboards are equipped with high-quality audio components to provide a superb audio experience. The exclusive AORUS AMP-UP Audio technology makes for the ideal onboard sound solution for the most demanding audiophiles.
Multi-Zone Light Show Design
Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs that surround the motherboard.
