Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard
Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard
Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard - 0
Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard - 0
Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard - 0
Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard - 0

Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard

0 Reviews
Stock : Out of Stock
PID : P0392506474
Brand : Gigabyte
Model : B450M S2H
Warranty : 3-Years
  • Chipset: AMD B450
  • Memory: 2 x DDR4, Max. 32 GB
  • Form Factor - Micro ATX ; 24.4cm x 20.5cm
  • Processors Supports - Up to AMD Ryzen 5000 series

Product Pricing

Discount Price

৳8,500 ৳9,800
+ Available Payment Method

EMI Start From*

৳299

PRODUCT SPECIFICATIONS

Processor

Supported CPU AM4 Socket

Support for AMD Ryzen 2nd Generation/ Ryzen

with Radeon Vega Graphics/ Athlon

with Radeon Vega Graphics/ Ryzen

1st Generation Processors

Mainboard

Chipset AMD B450
BIOS 1 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory Size 32 GB
Memory Type Dual channel memory architecture
Memory - Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules

- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

- Support for Extreme Memory Profile (XMP) memory modules

Storage

Supported Storage 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)

Supports only M.2 SATA SSDs when using an AMD Athlon 200-series/ 7th Generation A-series or Athlon APU.

4 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, and RAID 10

Graphics

Graphics 1 x D-Sub port, supporting a maximum resolution of 1920x1200 at 60 Hz



1 x DVI-D port, supporting a maximum resolution of 1920x1200 at 60 Hz

The DVI-D port does not support D-Sub connection by adapter.



1 x HDMI port, supporting a maximum resolution of 4096x2160 at 60 Hz(Note)

Support for HDMI 2.0 version and HDCP 2.2.(Note)



Maximum shared memory of 2 GB

(Note) Actual support may vary by CPU.



Max Shared Memory - 2 GB

Networking & Connectivity

LAN Realtek GbE LAN chip (10/100/1000 Mbit)

Audio & Microphone

Audio Realtek ALC887 codec

High Definition Audio

2/4/5.1/7.1-channel

To configure 7.1-channel audio, you have to use an

HD front panel audio module and enable

the multi-channel audio feature through the audio driver.

Support for S/PDIF Out

Ports

Connector D-Sub (s)

1 x D-Sub port, supporting a maximum resolution of 1920x1200 at 60 Hz



DVI-D (s)

1 x DVI-D port, supporting a maximum resolution of 1920x1200 at 60 Hz
Internal I/O Ports 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x system fan header

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x S/PDIF Out header

1 x CPU cooler LED strip/RGB LED strip header

1 x USB 3.1 Gen 1 header

2 x USB 2.0/1.1 headers

1 x speaker header

1 x Clear CMOS jumper

1 x chassis intrusion header
USB Chipset:

2 x USB 3.1 Gen 1 ports available through the internal USB header

6 x USB 2.0/1.1 ports (2 ports on the back panel,

4 ports available through the internal USB headers)

CPU:

4 x USB 3.1 Gen 1 ports on the back panel
HDMI 1 x HDMI port, supporting a maximum resolution of 4096x2160 at 60 Hz

Support for HDMI 2.0 version and HDCP 2.2.

1 x HDMI port

Software

Bundled Software Norton Internet Security (OEM version)

Realtek 8118 Gaming LAN Bandwidth Control Utility

Special Features

Special Features Support for APP Center

Available applications in APP Center may vary by motherboard model.

Supported functions of each application may also vary depending on
motherboard specifications.

BIOS

3D OSD

AutoGreen

Cloud Station

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

Smart Keyboard

Smart TimeLock

Smart HUD

Smart Survey

System Information Viewer

USB Blocker

Support for Q-Flash

Support for Xpress Install

Others

Other Features TPM (Trusted Platform Module )

1 x Trusted Platform Module (TPM) header

(2x6 pin, for the GC-TPM2.0_S module only)

Physical Specification

Color Black
Expansion Slots 1 x PCI Express x16 slot, running at x16

(The PCIEX16 slot conforms to PCI Express 3.0 standard.)

2 x PCI Express x1 slots

(The PCI Express x1 slot conforms to PCI Express 2.0 standard.)



M.2 Socket

1 x M.2 Socket 3 connector

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)

Supports only M.2 SATA SSDs when using an

AMD Athlon 200-series/ 7th Generation A-series or Athlon APU.
Form Factor Micro ATX Form Factor; 24.4cm x 20.5cm

Technical Info

Brand Gigabyte
Model B450M S2H

Warranty Information

Warranty 3-Years

PRODUCT DESCRIPTION

Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard in Bangladesh

Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard is a powerful and reliable choice for budget-friendly gaming and professional builds. It supports AMD Ryzen 2nd Generation, Ryzen with Radeon Vega Graphics, Athlon with Radeon Vega Graphics, and Ryzen 1st Generation Processors, making it a versatile option for various AMD setups. Built on the AMD B450 chipset, this motherboard ensures efficient performance, overclocking capabilities, and enhanced connectivity. Its Micro ATX form factor (24.4cm x 20.5cm) makes it compact while still providing essential features for a smooth and high-performance computing experience. The board comes with two DDR4 DIMM slots, supporting up to 32GB of RAM with speeds of up to 3200MHz (OC). Storage options include four SATA 6Gb/s ports and an M.2 slot, ensuring fast data transfers and reliable storage solutions. The PCIe x16 slot (3.0 standard) supports dedicated graphics cards, while the two PCIe x1 slots allow for additional expansions. For display output, the motherboard provides D-Sub, DVI-D, and HDMI ports, with HDMI supporting 4K resolution at 60Hz. Connectivity is seamless with Realtek GbE LAN, USB 3.1 Gen 1 ports, and high-quality audio powered by Realtek ALC887 codec, supporting 7.1-channel HD audio. Additional features like RGB Fusion support, Smart Fan 5, and Q-Flash for BIOS updates make it a user-friendly and future-proof motherboard. Whether you're building a gaming PC, a workstation, or a home entertainment system, the Gigabyte B450M S2H is a fantastic choice. Purchase it now from Tech Land BD and enjoy a 3-year warranty for complete peace of mind!

CUSTOMER REVIEWS

Login to write a review.

No reviews yet

Be the first to share your thoughts about this product.

What is the Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard Price in Bangladesh 2026 ?

The Gigabyte B450M S2H Price in BD is 8,500৳ . This Gigabyte B450M S2H AMD AM4 DDR4 Micro ATX Motherboard Manufacturing by Gigabyte Comes With 3-Years Warranty & Based on 0 reviews. Tech Land BD Offers you Gigabyte B450M S2H by 8,500৳ and its regular price is 9,800৳ Which is also Out of Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
