ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD
ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD
ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD - 1
ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD - 2
ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD - 3

ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD

0 Reviews
Stock : Discontinued
PID : P00025061179
Brand : Asus
Model : ROG STRIX B365-G
Warranty : 3 Years
  • Brand: Asus
  • Name: ASUS ROG STRIX B365-G RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD
  • Model: ROG STRIX B365-G

SPECIFICATIONS

Processor

Supported CPU Intel® 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® Turbo Boost Technology 2.0

Mainboard

Chipset Build in Intel® B365
BIOS 1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI6.1

Memory

Memory Intel® B365 Chipset
4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)

Storage

Supported Storage Intel® B365 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*2
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel® Rapid Storage Technology supports
Intel® Optane™ Memory Ready *

Graphics

Graphics Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : HDMI/DVI-D ports
- Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz

Networking & Connectivity

LAN Intel® I219V
Anti-surge LANGuard
ROG GameFirst Technology

Audio & Microphone

Audio ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
- Dual OP Amplifiers
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB (Line-out at rear) 113 dB SNR recording input
Audio Feature :
- SupremeFX Shielding™ Technology
- Optical S/PDIF out port(s) at back panel
- LED-lit Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference, with a gorgeous illuminated trace path
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
- Sonic Radar III
- Sonic Studio III + Sonic Studio Link

Ports

Slots 1 x PCIe 3.0 x16
1 x PCIe 3.0 x16 (max at x4 mode) *1
1 x PCIe 3.0 x1
Internal I/O Ports 1 x AAFP connector
1 x Aura RGB Strip Header
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 2 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 with E key for Wi-Fi module
1 x TPM header
1 x COM port(s) connector(s)
6 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s)
2 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x Front panel connector(s)
1 x Clear CMOS jumper(s)
External I/O Ports 1 x PS/2 keyboard/mouse combo port(s)
1 x DVI
1 x HDMI
2 x USB 3.1 Gen 2 (red)Type-A
4 x USB 3.1 Gen 1 (blue) Type-A
2 x USB 2.0
1 x Optical S/PDIF out
5 x Audio jack(s)
Anti-surge LAN (RJ45) port
USB Intel® B365 Chipset :
2 x USB 3.1 Gen 2 port(s)
Intel® B365 Chipset :
6 x USB 3.1 Gen 1 port(s)
Intel® B365 Chipset :
6 x USB 2.0 port(s)

Physical Specification

Form Factor mATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

Warranty Information

Warranty 03 Years

DESCRIPTION

ASUS ROG STRIX B365-G RGB INTEL mATX GAMING MOTHERBOARD

Specifications :

● LGA1151 socket: Ready for 9th/8th Gen Intel® Core™ desktop processors.

● Aura Sync RGB: Synchronize LED lighting with a vast portfolio of compatible PC gear, including RGB strips.

● Easy DIY: Pre-mounted I/O shield, ASUS SafeSlot and premium components for maximum endurance.

● Gaming connectivity: Dual M.2, USB 3.1 Gen 2 Type-A connectors, HDMI and DVI.

● Gaming networking: Intel Gigabit Ethernet, LANGuard and GameFirst for smoother, safer and lag-free online play.

● Gaming audio: SupremeFX S1220A teamed with Sonic Studio III creates immersive aural landscapes.

● Advanced cooling: Automated system-wide tuning and cooling profiles that are tailor-made for your rig.
**03 Year Warranty



ASUS RGB INTEL LGA-1151 mATX GAMING MOTHERBOARD

The ROG Strix B365-G Gaming MOTHERBOARD. Built in the micro-ATX form factor, this board packs many gamer essentials and is targeted at PC gamers who don't overclock. With its in-BIOS memory frequency setting capped at DDR4-2667, ASUS is very specific about the target audience. The board draws power from a combination of 24-pin ATX and 8-pin EPS power connectors, conditioning it for the CPU with a 7+2 phase VRM. The board supports all 9th-gen and 8th-gen Core "Coffee Lake/Refresh" processors out of the box.

The LGA1151 socket is wired to four DDR4 DIMM slots that support up to 64 GB of dual-channel DDR4-2667 memory, and the board's sole PCI-Express 3.0 x16 slot has a metal reinforcement. A PCI-Express 3.0 x1, M.2 E-key slot (for WLAN cards), and PCI-Express 3.0 x4 (physical x16), make for the rest of the expansion area. Storage connectivity includes two M.2-2280 slots, one of which supports both PCI-Express 3.0 x4 and SATA 6 Gbps, while the other is just PCI-Express 3.0 x4; and six SATA 6 Gbps ports. The board's sole 1 GbE interface is driven by an Intel i219-V controller. USB connectivity includes two type-A 10 Gbps USB 3.1 gen 2 ports, besides six USB 3.0 ports (four on the rear panel, two by headers). The onboard audio solution combines a Realtek ALC1220A CODEC with dual OPAMPs, EMI shielding, audio-grade capacitors, and ground-layer isolation. A couple of 3-pin addressable RGB headers make for the rest of this board
