CPU |
- Supports 10th Gen Intel® Core™ Processors (Socket 1200)
- Digi Power design
- 5 Power Phase design
- Supports Intel® Turbo Boost Max 3.0 Technology
|
Chipset | |
Memory |
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2933/2800/2666 / 2400 / 2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel® Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots
- *Please refer to Memory Support List on ASRock's website for more information.
- Core™ (i9/i7) support DDR4 up to 2933; Core™ (i5/i3), Pentium® and Celeron® support DDR4 up to 2666
|
Graphics |
- Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1**
- Graphics, Media & Compute: Microsoft® DirectX 12, OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1
- Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft® PlayReady 3.0, Intel® SGX Content Protection, UHD/HDR Blu-ray Disc
- Three graphics output options: D-Sub, DVI-D and HDMI* Supports up to 2 displays simultaneously
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
- Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- Supports HDCP 2.3 with DVI-D and HDMI 1.4 Ports
- Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port
- *Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
- **VP9 10bit and VC-1 are for decode only.
- VP8 and VP9 encode are not supported by Windows® OS.
|
Audio |
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)
- Supports Surge Protection
|
LAN |
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE
|
|
Slots |
- 1 x PCI Express 3.0 x16 Slot*
- 1 x PCI Express 3.0 x1 Slot
- *Supports NVMe SSD as boot disks
|
Software and UEFI | - Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock XFast LAN
- UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- *These utilities can be downloaded from ASRock Live Update & APP Shop
|
Storage Interface |
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
|
Support CD
| - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
|
Connectors
|
- - 1 x SPI TPM Header
- - 1 x Chassis Intrusion and Speaker Header
- - 1 x CPU Fan Connector (4-pin)*
- - 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- - 1 x 24 pin ATX Power Connector
- - 1 x 8 pin 12V Power Connector
- - 1 x Front Panel Audio Connector
- - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
- - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
- *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
|
Rare Panel I/O
|
- - 1 x PS/2 Mouse/Keyboard Port
- - 1 x D-Sub Port
- - 1 x DVI-D Port
- - 1 x HDMI Port
- - 4 x USB 2.0 Ports (Supports ESD Protection)
- - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
- - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- - HD Audio Jacks: Line in / Front Speaker / Microphone
|
Accessories
|
- - Quick Installation Guide, Support CD, I/O Shield
- - 2 x SATA Data Cables
|
H/W Monitoring
|
- - Temperature Sensing: CPU, Chassis/Water Pump Fans
- - Fan Tachometer: CPU, Chassis/Water Pump Fans
- - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans
- - Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans
- - CASE OPEN detection
- - CPU Core/Cache, GT, DRAM, PCH +1.0V, VCCST Voltage Multi-adjustment
|
BIOS
|
- - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
- - ACPI 6.0 Compliant wake up events
- - SMBIOS 2.7 Support
- - CPU Core/Cache, GT, DRAM, PCH +1.0V, VCCST Voltage Multi-adjustment
|
Unique Features
|
- ASRock Super Alloy
- - Premium 50A Power Choke
- - Sapphire Black PCB
- - High Density Glass Fabric PCB
- ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
- ASRock Live Update & APP Shop
|
|
Operating System
| - - Microsoft® Windows® 10 64-bit
|
Form Factor
|
- - Micro ATX Form Factor: 7.76-in x 7.4-in, 19.7 cm x 18.8 cm
- - Solid Capacitor design
|
