CPU |
- - Supports 10th Gen Intel® Core™ Processors (Socket 1200)
- - Digi Power design
- - 7 Power Phase design
- - Supports Intel® Turbo Boost Max 3.0 Technology
|
Chipset | |
Memory |
- - Dual Channel DDR4 Memory Technology
- - 2 x DDR4 DIMM Slots
- - Supports DDR4 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory*
- - Supports ECC UDIMM memory modules (operate in non-ECC mode)
- - Max. capacity of system memory: 64GB**
- - Supports Intel® Extreme Memory Profile (XMP) 2.0
- - 15μ Gold Contact in DIMM Slots
- *Please refer to Memory Support List on ASRock's website for more information.
- Core™ (i9/i7) support DDR4 up to 2933; Core™ (i5/i3), Pentium® and Celeron® support DDR4 up to 2666.
|
Graphics |
- - Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1**
- - Graphics, Media & Compute: Microsoft® DirectX 12, OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1
- - Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft® PlayReady 3.0, Intel® SGX Content Protection, UHD/HDR Blu-ray Disc
- - Three graphics output options: D-Sub, DVI-D and HDMI
- - Supports Triple Monitor
- - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
- - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
- - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
- - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- - Supports HDCP 2.3 with DVI-D and HDMI 1.4 Ports
- - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port
- *Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated
|
Audio |
- - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)
- - Supports Surge Protection
|
LAN |
- - Gigabit LAN 10/100/1000 Mb/s
- - Giga PHY Intel® I219V
- - Supports Wake-On-LAN
- - Supports Lightning/ESD Protection
- - Supports Energy Efficient Ethernet 802.3az
- - Supports PXE
|
|
Slots |
- - 1 x PCI Express 3.0 x16 Slot*
- - 2 x PCI Express 3.0 x1 Slots
- - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
|
Software and UEFI |
- Software
- - ASRock Motherboard Utility (A-Tuning)
- - ASRock XFast LAN
- UEFI
- - ASRock EZ Mode
- - ASRock Full HD UEFI
- - ASRock My Favorites in UEFI
- - ASRock Instant Flash
- - ASRock Internet Flash
- - ASRock Easy RAID Installer
- *These utilities can be downloaded from ASRock Live Update & APP Shop.
|
Storage Interface |
- - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and Hot Plug
- - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*
- *Supports Intel® Optane™ Technology
- Supports NVMe SSD as boot disks
- Supports ASRock U.2 Kit
|
Support CD
| - - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
|
Connectors
|
- - 1 x Print Port Header
- - 1 x COM Port Header
- - 1 x SPI TPM Header
- - 1 x Chassis Intrusion and Speaker Header
- - 1 x CPU Fan Connector (4-pin)*
- - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***
- - 1 x 24 pin ATX Power Connector
- - 1 x 8 pin 12V Power Connector
- - 1 x Front Panel Audio Connector
- - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
- - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
- *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
- **The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
|
Rare Panel I/O
|
- - 1 x Antenna Bracket
- - 1 x PS/2 Mouse/Keyboard Port
- - 1 x D-Sub Port
- - 1 x DVI-D Port
- - 1 x HDMI Port
- - 2 x USB 2.0 Ports (Supports ESD Protection)
- - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
- - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- - HD Audio Jacks: Line in / Front Speaker / Microphone
|
Accessories
|
- - Quick Installation Guide, Support CD, I/O Shield
- - 2 x SATA Data Cables
- - 2 x Screws for M.2 Sockets
|
H/W Monitoring
|
- - Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans
- - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
- - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
- - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
- - CASE OPEN detection
- - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH, VCCSA, VCCST
|
BIOS
|
- - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
- - ACPI 6.0 Compliant wake-up events
- - SMBIOS 2.7 Support
- - CPU Core/Cache, GT, DRAM, VPPM, PCH 1.05V, VCCST, VCCSA Voltage Multi-adjustment
|
Unique Features
|
- ASRock Super Alloy
- - Premium 50A Power Choke
- - Sapphire Black PCB
- - High-Density Glass Fabric PCB
- ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)
- ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
- ASRock Live Update & APP Shop
|
|
Operating System
| - Support for Windows 10 64-bit
|
Form Factor
|
- - Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
- - Solid Capacitor design
|
