BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD
BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD
BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD - 1
BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD - 2
BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD - 3

BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD

1 Reviews
Stock : In Stock
PID : P2482506030
Brand : Biostar
Model : B550MX/E PRO
Warranty : 3 Year
  • AMD B550 single chip architecture
  • Supports PCIe M.2 4.0 (64Gb/s)
  • Supports HDMI 4K resolution
  • Supports WiFi 6 module

Product Pricing

Discount Price

৳10,900 ৳12,000
+ Available Payment Method

EMI Start From*

৳384

SPECIFICATIONS

Processor

Supported CPU Socket AM4 support AMD Ryzen 3rd Gen (Matisse/ Renoir) and Ryzen 4th Gen (Vermeer/ Future) processors
Support for future AMD Ryzen processors with BIOS update

Mainboard

Chipset AMD B550

Memory

Memory 4th Gen AMD Ryzen Processors (Vermeer CPUs/ Future APUs)

Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133

3rd Gen AMD Ryzen Processors (Matisse CPUs): Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133

3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs): Supports Dual Channel DDR4 4933+(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133

4 x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB of Memory

Each DIMM supports non-ECC and ECC Un-buffered 8/ 16/ 32 GB DDR4 module

Storage

Supported Storage Total supports 2 x M.2 socket and 4 x SATA III (6Gb/s) ports

4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10

1 x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCIe 4.0 x4 (64Gb/s)/ 3.0 x4 (32Gb/s) & SATA III (6.0Gb/s) SSD

1 x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA):

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCIe 3.0 x4 (32Gb/s) & SATA III (6.0Gb/s) SSD

Networking & Connectivity

LAN Realtek RTL8111H

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Audio & Microphone

Audio ALC897

7.1 Channels, High Definition Audio, Hi-Fi (Front)

Ports

Slots AMD Ryzen 5000/3000 Series Processors

1 x PCIe 4.0 x16 Slot (x16 or x4/x4/x4/x4 mode) or AMD Ryzen 5000 G/4000 G Series Processors

1 x PCIe 3.0 x16 Slot (x16 or x8/x4/x4 mode)

AMD B550 Chipset

1 x PCIe 3.0 x16 Slot (x4 mode)

1 x PCIe 3.0 x1 Slot

* According to different CPUs will have different speeds.

* PCIe 4.0 speed only for AMD Ryzen 3rd Gen Matisse and 4th Gen Vermeer CPUs.

* When using PCIe x1 slot (PCIEG3X1), PCIe x16 slot (PCIEG3X4) will be adjusted to x2 lanes.
Internal I/O Ports 4 x SATA III (6.0Gb/s) Connectors

1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module

2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

8-Pin Power Connector

24-Pin Power Connector

CPU Fan Connector

2 x System Fan Connectors

Front Panel Header

Front Audio Header

Internal Stereo Speaker Header

Clear CMOS Header

S/PDIF out Connector

COM Port Header

TPM Header

SYSTEM Status LED

* M.2 (E key) Wi-Fi card is not provided
External I/O Ports 2 x WIFI Antenna Ports

1 x PS/2 Keyboard / Mouse

1 x DVI-D Port

1 x VGA Port

1 x HDMI Port

1 x LAN port

4 x USB 3.2 (Gen1) Ports

2 x USB 2.0 Ports

3 x Audio Jack
USB 6 x USB 3.2 (Gen1) ports (4 on rear I/Os and 2 via internal headers)

6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers)
HDMI 1 x HDMI Port

Physical Specification

Dimension Micro ATX Form Factor Dimension: 24.4cm x 24.4cm ( W x L )

Warranty Information

Warranty 3 Year

DESCRIPTION

BEST BIOSTAR B550MX/E PRO MOTHERBOARD PRICE IN BANGLADESH

The BIOSTAR B550MX/E PRO DDR4 AMD AM4 Micro ATX Motherboard is a powerful and versatile motherboard that supports AMD Ryzen 3rd Gen (Matisse/ Renoir) and Ryzen 4th Gen (Vermeer/ Future) processors. With a compact Micro ATX form factor and AMD B550 chipset, this motherboard offers a range of features including Realtek ALC897 audio with 7.1 channel support, Hi-Fi front audio, and multiple expansion slots for PCIe and M.2 sockets. The board can support up to 128GB of DDR4 memory across 4 DIMM slots, with support for dual-channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133. This makes it ideal for demanding applications such as gaming or content creation. In addition, the BIOSTAR B550MX/E PRO motherboard also offers HDMI, VGA, and DVI-D outputs for graphics, as well as USB 3.2 (Gen1) and USB 2.0 ports for connectivity. It also comes with Realtek RTL8111H LAN port for fast internet connection, wireless communication module, and support for RAID 0, 1, 10 storage. To top it off, the BIOSTAR B550MX/E PRO motherboard includes special features like A.I FAN and PCIe M.2 4.0. And with a manufacturing warranty of 3 years, you can rest assured that your investment is protected.If you're looking for a reliable and feature-rich motherboard at the best price in Bangladesh's techland, the BIOSTAR B550MX/E PRO DDR4 AMD AM4 Micro ATX Motherboard is an excellent choice.

REVIEWS

Login to write a review.

Overall Rating

5 out of 5 stars
1
Total Reviews
5 star
1
4 star
0
3 star
0
2 star
0
1 star
0
Ami akta warrior

Can I use this motherboard with arc750 and r5 5500/5600

26 May, 2024

What is the BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD Price in Bangladesh 2026 ?

The Biostar B550MX/E PRO Price in BD is 10,900৳ . This BIOSTAR B550MX/E PRO MICRO AM4 DDR4 ATX AMD MOTHERBOARD Manufacturing by Biostar Comes With 3 Year Warranty & Based on 1 reviews. Tech Land BD Offers you Biostar B550MX/E PRO by 10,900৳ and its regular price is 12,000৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
