Name: ASUS TUF H470-PRO Wifi GAMING Mainboard
Brand: Asus
Availability: OutOfStock

ASUS TUF H470-PRO Wifi GAMING Mainboard

-100 % Out Of Stock

ASUS TUF H470-PRO Wifi GAMING Mainboard
Stock Status	Out Of Stock
Product ID	15888
Brand	Asus
Product model	H470 Pro
Warranty	3 years
Total Reviews	Based on 0 reviews. - Write a review

Based on 0 reviews. - Write a review

Out Of Stock

Add to Wish List Compare this Product

Short Description

Chipset: Build-in Intel H470

Multi-GPU Support: AMD 2-Way CrossFireX Technology

Intel 10th Gen Processors 1 x PCIe 3.0 x16 (x16 mode)

Intel H470 Chipset 1 x PCIe 3.0 x16 (x4 mode) 4 x PCIe x1

View details

Product Information Declaimer

Stock availability is subject to change. Please confirm availability before shopping by calling us.
The product image is for illustration purposes only. The actual product may vary in size, color, and layout. No claim will be accepted for an image mismatch.
Tech Land BD can change the price of any product at any moment due to the volatile price of the technology.
We cannot guarantee that the information on this page is 100% correct. Tech Land BD is not responsible for the results obtained from the use of this information.

Processor
Supported CPU	Build in Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** * Refer to www.asus.com for CPU support list **Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
Mainboard
Chipset	Build in Intel H470
Memory
Memory	4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem * 10th Gen Intel Core i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Storage
Supported Storage	Total supports 2 x M.2 slot(s) and 5 x SATA 6Gb/s ports Intel H470 Chipset : 1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*1 1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 5 x SATA 6Gb/s port(s) Support Raid 0, 1, 5, 10 Intel Rapid Storage Technology supports Intel Optane Memory Readydy
Graphics
Multi-GPU	Supports AMD 2-Way CrossFireX Technology
Graphics	Integrated Graphics Processor 1 x DisplayPort 1.4 ** 1 x HDMI 1.4b Graphics specifications may vary between CPU types. *Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.
Audio & Microphone
Audio	Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - Optical S/PDIF out port(s) at back panel - Audio cover - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
Networking & Connectivity
LAN	Intel I219-V 1Gb Ethernet TUF LANGuard
Ports
Slots	Intel 10th Gen Processors 1 x PCIe 3.0 x16 (x16 mode) Intel H470 Chipset 1 x PCIe 3.0 x16 (x4 mode) 4 x PCIe x1
Internal I/O Ports	1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 2 x Aura RGB Strip Headers 1 x Addressable Gen 2 header(s) 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 1 USB 2.0 port(s) 2 x M.2 Socket 3 5 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Chassis intrusion header is inbuilt) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
External I/O Ports	1 x PS/2 keyboard/mouse combo port(s) 1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®) 2 x USB 3.2 Gen 1 (blue) Type-A 2 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jack(s)
USB	Rear USB Port ( Total 6 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 2 x USB 2.0 port(s) Front USB Port ( Total 7 ) 2 x USB 3.2 Gen 1 port(s)(4 x Type-A) 1 x USB 2.0 port(s)(2 x Type-A) 1 x USB 2.0 port(s)(1 x Type-A)
Technical Info
BIOS	192 (128+64) Mb Flash ROM, UEFI AMI BIOS
Physical Specification
Form Factor	ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Warranty Information
Warranty	3 years warranty

ASUS H470-PRO TUF GAMING Mainboard in Bangladesh

The ASUS H470-PRO LGA 1200 ATX Motherboard is meant round the Intel H470 chipset, supporting 10th Gen Intel Core, Pentium Gold, and Celeron processors with an LGA 1200 socket. it's four memory slots, supporting up to 128GB of dual-channel DDR4 RAM, which may run up to 2933 MHz. There are six SATA III ports and two M.2 slots for storage. This motherboard features an ATX form factor, allowing use in mid-tower and full tower cases. Other integrated features include Realtek RTL8111H Gigabit Ethernet and RealTek ALC887 8-channel high-definition audio.

Intel H470 Chipset

This motherboard features the Intel H470 Chipset and therefore the Intel LGA Socket 1200, making it ready for 10th Gen Intel Core, Pentium Gold, and Celeron processors.

ASUS OptiMem Technology

ASUS OptiMem technology carefully maps memory signal pathways across different PCB layers to scale back vias and adds shielding zones that significantly reduce crosstalk. this enables for improved memory stability and compatibility, lower memory latencies at equivalent voltages, and improved memory frequency margin.

Storage

The dual M.2 slots support data transfer rates of up to 32 Gb/s via PCIe 3.0 x4 bandwidth, enabling quicker boot times and app load times with OS or application drives.

VRM Heatsink and Thermal Pads

The VRM heatsinks with underneath thermal pads improve heat transfer from the MOSFETs for better cooling performance.

Audio

This motherboard separates analog and digital signal domains, significantly reducing the multi-lateral interface. Crosstalk is minimized by the separate layer between left and right tracks.

SafeSlot Core+

SafeSlot Core+ is that the ASUS-exclusive PCIe slot. The slot is fortified with a one-piece chrome steel brace that shields the slot from damage. The metal cover secures tightly to the slot with hooks. the whole design is firmly anchored to the PCB with strengthened solder points to supply a secure foundation for heavy graphics cards.
