|Supported CPU||AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors|
|Memory||4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory 4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Dual Channel Memory Architecture OptiMem II ECC Memory (ECC mode) support varies by CPU.|
|Graphics||Integrated Graphics Processor DisplayPort 1.2 HDMI 2.1(4K 60HZ)|
|Multi-GPU Support||Supports AMD 2-Way CrossFireX Technology|
|Slots||1 x PCIe 4.0 x16 (x16 mode) AMD B550 Chipset 1 x PCIe 3.0 x16 (x4 mode) * 3 x PCIe 3.0 x1 1 x PCIe 3.0 x16 (x16 mode)|
|Supported Storage||1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) AMD B550 Chipset : Support Raid 0, 1, 10 Total supports 2 x M.2 slot(s) and 6 x SATA 6Gb/s ports 1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)* 1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s port(s), AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors : AMD RyzenTM 4000 G-Series Processor :|
|LAN||Intel I225-V 2.5Gb Ethernet ASUS LANGuard|
|Audio||ROG SupremeFX8-Channel High Definition Audio CODEC S1220A - Dual OP Amplifiers - Impedance sense for front and rear headphone outputs - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality120dBSNR stereo playback outputand113dBSNR recording input - Supports up to 32-Bit/192kHz playback * Audio Feature : - SupremeFX Shielding™ Technology - Gold-plated jacks - Optical S/PDIF in port(s) at back panel - Audio Shielding - Premium Japanese audio capacitors - Audio Cover * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.|
|USB Port||Rear USB Port ( Total 8 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 2 x USB 2.0 port(s) Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s) 4 x USB 2.0 port(s)|
|Internal I/O Ports||1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 1 x AAFP connector 2 x Aura RGB Strip Header(s) 1 x Addressable Gen 2 header(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 1 with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) 1 x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x System panel(s) 1 x Thermal sensor connector(s) 1 x Clear CMOS jumper(s)|
|External I/O Ports||1 x Intel® I225-V 2.5Gb Ethernet 1 x DisplayPort 1 x HDMI 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®) 4 x USB 3.2 Gen 1 2 x USB 2.0 1 x Optical S/PDIF out 1 x BIOS FlashBack™ Button(s) 5 x Gold-plated audio jacks|
|DIMENSIONS||9.6 x 12.0" / 24.4 x 30.5 cm|
|Form Factor||ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )|
|BIOS||256 Mb Flash ROM, UEFI AMI BIOS|
|HDMI||HDMI 2.1(4K 60HZ)|
ASUS ROG Strix B550-A Gaming AM4 ATX MotherboardGet ample connectivity without skimping on performance with the ROG Strix B550-A Gaming AM4 ATX Motherboard from ASUS. Designed for use with CPUs using the AM4 socket, this board features the AMD B550 chipset. Install up to 128GB of dual-channel DDR4 RAM across four slots, with speeds up to 5100 MHz supported when overclocking. Storage drives can be installed using six SATA III connectors or two M.2 slots. Up to two graphics cards can be installed using PCIe 4.0 x16 and PCIe 3.0 x16 slots, with support for 2-way AMD CrossFireX. Other adapter cards can be installed in three PCIe 3.0 x1 slots.
A rear I/O panel sports a USB 3.2 Gen 2 Type-A and Type-C port, as well as four USB 3.2 Gen 1 and two USB 2.0 Type-A ports. Connect displays using the DisplayPort or HDMI outputs, or connect the audio using a S/PDIF port or five 3.5mm jacks. An RJ45 port supports 2.5 Gigabit Ethernet, while a BIOS flashback button is also present. The ASUS ROG Strix B550-A Gaming AM4 ATX Motherboard utilizes the SupremeFX S1220A audio codec and supports Windows 10 64-bit operating systems.
AMD B550 Chipset
This motherboard uses the AMD B550 chipset and is compatible with AMD CPUs using the AM4 socket.
The ROG Strix B550-A Gaming features two M.2 slots, one of which supports the PCIe 4.0 standard to provide optimum storage and data speeds via the 3rd Gen AMD Ryzen platform. Both M.2 slots support up to the type 22110 socket and NVM Express RAID for a performance boost.
ProCool Power Connector
The ProCool socket is built to ensure flush contact with the PSU powerlines, enabling lower impedance and efficient heat dissipation.
DIGI+ Power Control
ASUS DIGI+ Power Control allows you to tune VRAM and DRAM voltage for optimal system efficiency, stability, and performance.
Alloy Chokes and Capacitors
Alloy chokes and capacitors are designed to resist extreme temperatures.
This layered PCB dissipates heat around the VRM, improving overall system stability while providing overclocking headroom.
Intel 2.5 Gigabit Ethernet
Onboard 2.5 Gigabit Ethernet gives your wired connection a boost, with speeds that are 2.5 times faster than standard Ethernet connections for speedy file transfers, lag-free gaming, and high-res video streaming.
Built-in ROG SupremeFX audio technology provides accurate audio and two front-panel op-amp outputs for gaming headsets.
What is the ASUS ROG Strix B550-A Gaming AM4 ATX Motherboard Price in Bangladesh?The ASUS ROG Strix B550-A Gaming AM4 ATX Motherboard Price in BD is 20,300৳ in Today's 2021-12-01 Market. This ROG Strix B550-A Manufacturing by Asus SKU of Comes With Warranty & Based on 0 reviews. Tech Land BD Offers you Asus ROG Strix B550-A 19,600৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
|Product Name||ASUS ROG Strix B550-A Gaming AM4 ATX Motherboard|
|Product model||ROG Strix B550-A|
|Total Reviews||Based on 0 reviews.|
|Last Edit date||11/30/2021|
