Zigor Deba Pro 1500 UPS Specification
|
GENERAL
| - Model: Deba Pro 1500
- Power: 1500VA/900W
- Topology: Line-interactive with AVR
|
INPUT
| - Voltage range: 145-290 VAC
- Rated voltage: 220/230 VAC
- Frequency: 60/50 Hz (auto-sensible)
|
OUTPUT
| - Voltage (normal mode): 220/230 VAC
- Voltage regulation: ±10%
- Frequency range (battery mode): 60 Hz/50 Hz ±1 Hz
- Type of wave (battery mode): Simulated senoidal
- Outputs: 2/4 Universal Outputs
- Transfer time: 2-6 ms typical
|
BATTERIE
| - Standard battery: Lead battery with an anti-leak seal, VRLA type
- Included battery: 12 V/9 Ah x 2
- Backup time: Up to 15 minutes depending on load
- Charge time: 4-6 hours recover to 90% capacity
|
INDICATORS
| - Led/LCD display: Green Led: normal main, battery mode
- Acoustics: Battery mode, low battery, battery change, overload, and fault
|
COMMUNICATIONS
| - Communications: USB/RS232 (optional) port
- Cold start: Yes
- Software: ViewPower
|
PROTECTION
| - Overload: Yes
- Battery low voltage: Yes
|
| OTHERS | - Dimension WxDxH (mm): 345 x 146 x 162
- Weight (Kg): 9.2
|
Zigor Deba Pro 1500 UPS Comes With 1-year Guaranty* (battery included)
|
Zigor Deba Pro 1500 UPS in Bangladesh
Designed for servers, point-of-sale, routers, switches, hubs, and other network devices, the Zigor Deba Pro UPS from Zigor delivers intelligent and efficient network power protection from entry level to scaleable runtime. It can provide up to 15 minutes Backup*(depending on load) , It features an output of 720W / 1500kVA, an input of 145V to 290V @ 60 Hz ±1 Hz, V/7.5 Ah x 2 VRLA type battery, line-interactive topology. ViewPower management software helps to provide unattended, yet proper shutdowns of network operating systems, and also included USB cable. Support is provided by a limited 1-year warranty.
Important Features:
- Line-interactive
- Reduced size
- 2/4 Universal outputs
- USB communication port (Optional)
- AVR Stabilizer
- Uninterrupted power supply:
It protects your data supplying power from the battery before main failures - Microprocessor control:
UPS circuits are managed by a microprocessor which decreases UPS size and increases its reliability - Alarms:
led and acoustic alarms before main failures - High-quality battery:
high-quality lead battery with an anti-leak seal ensures a long life to improve operating economy - Battery self-test function:
when UPS starts, automatically it checks battery capacity - Protection against overvoltage:
it protects connected equipment against the main overvoltage - Automatic charge:
UPS always charge battery when it is connected to the main power - Automatic restart
