Specification:
●︎ Model: PG 1200 VA – P S
●︎ Power (VA/W) Requirements: 1200 VA / 720W
Input
●︎ Voltage Range: 145-280VAC
●︎ Frequency: 50/60Hz+/-5%
Output
●︎ Voltage (Inverter Mode): 220/230VAC+/-10%
●︎ Capacity: 720W
●︎ Frequency (Inverter Mode): 50/60Hz+/-5%
●︎ Transfer Time: 2~6ms typical
●︎ Waveform: Modified-Sinewave
Protection
●︎ Spike & Surge Suppression: Yes
●︎ Over/Under Volt. Switch to Bat. O / P: when main over regulation range
●︎ Over load /short Circuit: Fuse & current linited for both Mains and Battery modes
Function
●︎ Cool start: Cool start computer even there is no main power
●︎ Automatic recharge: Automatic recharge even UPS is off
●︎ Body Type: Metal
INDICATORS
●︎ AC Mode: Green lighting
●︎ Battery Mode: Red lighting
●︎ Over Load: Yellow lighting
Battery
●︎ Type: Lead-Acid Miantenance-Free
●︎ DC Bus: 12V 8.2Ah
●︎ Number: 2 PCS
●︎ Recharge time: 6 hours up to 90% capacity
●︎ Back up time: 05-40 mins (Depending on load)
Environmental
●︎ Temperature: -5-45 DegreeC
●︎ Humidity: 20% to 90%
**Warranty: 01 Year Battery & 02 Years Service with Spare Parts
Automatic voltage ragulation(AVR), Wide Input Voltage Range Option, High/Low Voltage Protection, Overload/Short Protection, Cool start computer even there is no main power, Automatic recharge even UPS is off, Beeping Alarm, LED indicator, Frequency Selection Automatically, Intelligent Battery Management, Compatibility with generators .
