MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD

MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
Out Of Stock
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD
Stock Status
Out Of Stock
Product ID
10016
Brand
MSI
Product modelMPG X570 GAMING EDGE WIFI
Warranty 3 years
Total Reviews
Short Description
  • Chipset: AMD X570 Chipset
  • Memory: 4x DDR4 memory slots, up to 128GB
  • LAN: 1x Realtek  8111H Gigabit LAN Controller
  • Audio: 7.1-Channel High Definition Audio Supports
    • Stock availability is subject to change. Please confirm availability before shopping by calling us.
    • The product image is for illustration purposes only. The actual product may vary in size, color, and layout. No claim will be accepted for an image mismatch.
    • Tech Land BD can change the price of any product at any moment due to the volatile price of the technology.
    • We cannot guarantee that the information on this page is 100% correct. Tech Land BD is not responsible for the results obtained from the use of this information.
    Mainboard
    Chipset AMD® X570 Chipset
    Memory
    Memory 4x DDR4 memory slots, support up to 128GB
    Storage
    Supported Storage 6x SATA 6Gb/s ports 2x M.2 slots (Key M) M2_1 slot(from AMD® Processor) - Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™) - Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) - Supports 2242/ 2260/ 2280/ 22110 storage devices M2_2 slot (from AMD® X570 Chipset) - Supports PCIe 3.0 x4 and SATA 6Gb/s - Supports 2242/ 2260/ 2280 storage devices
    Graphics
    Graphics 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz1
    Audio & Microphone
    Audio 7.1-Channel High Definition Audio Supports Optical S/PDIF output
    Networking & Connectivity
    LAN 1x Realtek® 8111H Gigabit LAN Controller
    Ports
    Slots 1x PCIe 4.0/3.0 x16 slot (PCI_E1) 3rd Gen AMD Ryzen™ support PCIe 4.0 x16 mode 2nd Gen AMD Ryzen™ support PCIe 3.0x16 mode Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8 mode 1x PCIe 4.0/ 3.0 x16 slot (PCI_E3, supports x4 mode) 3x PCIe 3.0 x1 slots1
    Internal I/O Ports 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 1x 4-pin ATX 12V power connector 6x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump connector 4x 4-pin system fan connectors
    USB 6x USB 3.2 Gen 1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.2 Gen 1 connectors) 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
    Warranty Information
    Warranty 3 years

    MSI MPG X570 GAMING EDGE WIFI MOTHERBOARD

    Specification:

    ●︎ Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4

    ●︎ Supports DDR4 Memory

    ●︎ Lightning Fast Game experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr, StoreMI, AMD Turbo USB 3.2 GEN2

    ●︎ Frozr Heatsink Design:  Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers.

    ●︎ Set Core Power Free: Extended Heatsink Design, Core Boost, Digital PWM IC, 8+4 pin CPU power connector, Game Boost, DDR4 Boost

    ●︎ MYSTIC LIGHT: 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip.

    ●︎ AUDIO BOOST 4 with NAHIMIC 3: Reward your ears with studio grade sound quality for the most immersive gaming experience

    ●︎ Dragon Center: A brand new software which integrates all MSI tools like GAME MODE, VOICE BOOST, LIVE UPDATE, AMBIENT LINK  with user friendly user interface.

    **3 Years Warranty


    MSI GAMING MOTHERBOARD

    The MPG X570 GAMING EDGE WIFI MOTHERBOARD from MSI is built on the AMD X570  chipset, supporting Ryzen processors with an AM4 socket. It has four memory slots that can hold up to 128GB of DDR4 RAM running at up to 3466 MHz when overclocked. For storage, it's equipped with six SATA III ports and a single M.2 slot, which utilizes the PCIe 3.0 x4 interface for speeds of up to 32 Gb/s when used with an appropriate drive. While it's equipped with DVI-D and HDMI outputs for integrated graphics, this motherboard also has one PCIe 3.0 x16 slot for a graphics card as well as a PCIe 2.0 x16 and two PCIe 2.0 x1 slots for other PCIe-based hardware. Other notable integrated features include Realtek ALC1220 7.1-channel HD audio, Realtek 8111H Gigabit LAN, and MSI Mystic Light RGB lighting.


    Frozr Heatsink Design

    Designed with the patented fan and double ball bearings to

    provide best performance for enthusiast gamers and

    prosumers.

    Core Boost

    With premium layout and fully digital power design to support

    more cores and provide better performance.

    Extended Heatsink Design

    MSI extended PWM and enhanced circuit design ensures

    even high-end processors to run in full speed.

    Lightning Gen4 solution

    The latest Gen4 PCI-E and M.2 solution with up to 64GB/s

    bandwidth for maximum transfer speed.

    M.2 Shield FROZR

    M.2 thermal accessory. Keeps M.2 SSDs safe while

    preventing throttling, making them run faster.

    DDR4 Boost

    Advanced technology to deliver pure data signals for the

    best gaming performance and stability.

    Audio Boost 4

    Isolated audio with a high quality audio processor for the

    most immersive gaming experience.

    Flash BIOS Button

    Simply use a USB key to flash any BIOS within seconds,

    without installing a CPU, memory or graphics card.
