MSI MEG X870E ACE MAX DDR5 AM5 Motherboard
MSI MEG X870E ACE MAX DDR5 AM5 Motherboard
MSI MEG X870E ACE MAX DDR5 AM5 Motherboard - 1
MSI MEG X870E ACE MAX DDR5 AM5 Motherboard - 2
MSI MEG X870E ACE MAX DDR5 AM5 Motherboard - 3

MSI MEG X870E ACE MAX DDR5 AM5 Motherboard

0 Reviews
Stock : In Stock
PID : P0332608001
Brand : MSI
Model : MEG X870E ACE MAX
Warranty : 3 Years
  • AMD AM5 Socket
  • X870E Chipset
  • DDR5 256GB Support
  • PCIe 5.0 Ready

Product Pricing

Discount Price

৳95,000 ৳105,000
+ Available Payment Method

EMI Start From*

৳3,345

SPECIFICATIONS

Processor

Supported CPU

Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset

MEG X870E ACE MAX

Mainboard

BIOS

Flash BIOS Button

Memory

Memory

256GB

Storage

Raid

Supports RAID 0, RAID 1, and Raid 10 for SATA storage devices

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Supported Storage
5x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280 devices
4x SATA 6G

M.2_1:
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)
M.2_2:
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors)

Graphics

Graphics

1x HDMI™

Support HDMI™ 2.1 FRL, maximum resolution of 8K 60Hz*

2x Type-C DisplayPort

USB4 port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K@120Hz*

Networking & Connectivity

LAN

1x Marvell® AQC113CS 10Gbps LAN

1x Realtek® 8126 5Gbps LAN
WiFi
Wi-Fi 7 Solution
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Bluetooth

Supports Bletooth® 5.4**, MLO, 4KQAM

Audio & Microphone

Audio

Realtek® ALC4082 Codec + ESS9219Q Combo DAC/HPA

7.1-Channel USB High-Performance Audio

Supports S/PDIF output

Supports up to 32-Bit/384 kHz playback on front panel

Ports

Internal I/O Ports

1x Power Connector(ATX_PWR)

2x Power Connector(CPU_PWR)

1x Power Connector(PCIE_PWR 8pin)

1x Front Type-C Quick Charge Connector(PD_PWR1)

1x CPU Fan

2x Combo Fan (Pump_Sys Fan)

5x System Fan

1x EZ Conn-header (JAF_2)

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Water Flow connector

1x Front Audio (JAUD)

2x Thermal Sensor connectors(T_SEN)

1x Tuning Controller connector(JDASH)

3x Addressable V2 RGB LED connector (JARGB_V2)

1x RGB LED connector(JRGB)

1x TPM pin header(Support TPM 2.0)

V-check point

2x Direct OC Jumper (JBCLK)

4x USB 2.0 ports

4x USB 5Gbps Type A ports

1x USB 20Gbps Type C ports
USB

4x USB 2.0 (Front)

4x USB 5Gbps Type A (Front)

9x USB 10Gbps Type A (Rear)

2x USB 10Gbps Type C (Rear)

1x USB 20Gbps Type C (Front)

2x USB 40Gbps Type C (Rear)
HDMI

1x HDMI 2.1 FRL (Supports up to 8K @ 60Hz)

Others

Other Features
LED FEATURE
1x EZ Digi-Debug LED
4x EZ Debug LED
1x EZ Memory Detection LED
1x EZ LED Control switch

Physical Specification

Weight

2kg

Warranty Information

Warranty

3 years

DESCRIPTION

MSI MEG X870E ACE MAX AMD AM5 ATX Motherboard at the Best Price in Bangladesh

The MSI MEG X870E ACE MAX AMD AM5 ATX Motherboard is a premium flagship motherboard designed for high-performance gaming PCs, enthusiast builds, AI workloads, and professional workstations. Powered by the advanced AMD X870E chipset, this motherboard supports the latest AMD Ryzen 9000, 8000, and 7000 Series desktop processors with the AM5 socket platform. Built for extreme performance, the MEG X870E ACE MAX features a powerful 18 Duet Rail Power System with 110A Smart Power Stage, providing stable power delivery for demanding CPUs and overclocking.

The motherboard supports up to 256GB DDR5 memory with high-speed overclocking support up to DDR5 9000+ MT/s (OC), along with AMD EXPO technology for optimized gaming performance. For next-generation connectivity, this ATX motherboard comes with PCIe 5.0 expansion slots, high-speed storage support, USB4 Type-C, Wi-Fi 7, and premium networking options including 10G LAN and 5G LAN. It also features advanced cooling solutions, including MSI Frozr thermal design, M.2 Shield Frozr, and a high-quality PCB to maintain stable performance under heavy workloads. The MSI MEG X870E ACE MAX is an excellent choice for users building a future-ready gaming rig or professional workstation. With premium power delivery, advanced connectivity, DDR5 support, and PCIe 5.0 technology, it delivers the performance and reliability required for high-end PC configurations.


Why Buy MSI MEG X870E ACE MAX Motherboard from Tech Land BD?

Buy the MSI MEG X870E ACE MAX AMD AM5 Motherboard from Tech Land BD to get a 100% genuine MSI product with official warranty support. Enjoy competitive pricing, fast nationwide delivery, secure online shopping, and reliable after-sales service from one of Bangladesh's trusted technology retailers.


FAQ

Which processors are supported by MSI MEG X870E ACE MAX?

The motherboard supports AMD Ryzen 9000, Ryzen 8000, and Ryzen 7000 Series desktop processors with the AM5 socket.

How much RAM does MSI MEG X870E ACE MAX support?

It supports up to 256GB of DDR5 RAM across four DDR5 UDIMM slots, with high-speed memory overclocking support.

Does this motherboard support PCIe 5.0?

Yes, the MSI MEG X870E ACE MAX supports PCIe 5.0 technology for next-generation graphics cards and high-speed storage devices.
