MSI MAG X570 TOMAHAWK WiFi Motherboard Specification
|
CPU
| - Chipset: AMD X570
- CPU Socket: AM4
|
Back Panel I/O
| - 3 x USB 3.1 / USB 3.2 Gen 2 Type-A
- 1 x USB 3.1 / USB 3.2 Gen 2 Type-C
- 2 x USB 3.1 / USB 3.2 Gen 1 Type-A
- 2 x USB 2.0 Type-A
- 1 x HDMI 1.4Output
- 5 x 3.5 mm
- 1 x S/PDIF
- 1 x Realtek 8125B 2.5Gigabit
- Wi-Fi Antenna: 2 x Connector
- Buttons: BIOS Flashback
|
Memory
| - Memory Slots: 4 x 288-Pin
- Memory Support: DDR4 1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600 MHz
- Maximum Capacity: 128 GB
- Channel Architecture: Dual Channel
- ECC Support: Non-ECC, ECC (Non-ECC Mode) Unbuffered
|
Storage Expansion
| - 6 x SATA III
- 2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, PCIe 3.0 x4)
- 1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, PCIe 3.0 x4, SATA III)
- RAID 0, 1, 10
|
Internal I/O | - 1 x PCIe 4.0 x16 (x16 mode)
- 1 x PCIe 4.0 x16 (x4 mode)
- 2 x PCIe 3.0 x1
- 1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)
- 2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)
- 2 x USB 2.0 Header (Supports 4 USB Type-A Port)
- 2-Way AMD CrossFireX
- 1 x 4-Pin CPU
- 4 x 4-Pin System
- 1 x 4-Pin Pump
- 1 x 24-Pin Mainboard
- 1 x 8-Pin ATX
- 1 x 4-Pin ATX
- Security Chassis Intrusion, TPM Module
- 4 x RGB
- 1 x Speaker
- 2-Digit Debug LED, Clear CMOS
- Legacy: 1 x Serial
|
Wireless | - Bluetooth: 5.1
- Wi-Fi: Wi-Fi 6 (802.11ax) (MU-MIMO)
- Module Support: 1 E Key M.2
|
Others | - BIOS
- ROM: 256 Mb
- Front Panel I/O
I/O Connection Headers: AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2 - Audio
Audio Codec: Realtek ALC1200 (7.1-Channel) - Form Factor: ATX
- Dimensions: 12.01 x 9.61" / 30.5 x 24.4 cm
|
MSI MAG X570 TOMAHAWK WiFi Motherboard Comes with 03 Years Warranty
|
MSI MAG X570 TOMAHAWK WiFi Motherboard in Bangladesh
Take your gaming experience to the next level by including the MSI Mag X570 Tomahawk WIFI AM4 ATX Motherboard in your high-performance computer build. Designed for gamers, enthusiasts, and content creators, this motherboard is powered by the AMD X570 chipset and supports 2nd and 3rd generation AMD Ryzen processors with the AM4 socket. It takes full advantage of the large PCIe 4.0 data bandwidth to deliver high performance for tasks such 3D rendering, video editing, and more. Up to 128GB of dual-channel DDR4 RAM, reaching 4600 MHz when overclocked, can be installed across four memory slots. The ATX motherboard also features advanced cooling and supports up to three M.2 SSDs and six SATA III storage drives, which can be put into RAID 0, 1, or 10 configuration. Its two PCIe 4.0 x16 slots can accommodate the 2-Way AMD CrossFireX configuration to maximize your system's graphical capabilities for high frame rates, connecting 4K monitors, and faster video rendering times. Alternatively, the built-in HDMI port allows you to take advantage of integrated CPU graphics. Two additional PCIe 3.0 x1 slots are available for compatible expansion cards.
Connect compatible peripherals to the USB 3.2 Gen 2 Type-A and Type-C ports to transfer data at up to 10 Gb/s. Play online games and stream video using the fast 2.5 Gigabit Ethernet port or the built-in 802.11ax Wi-Fi, which can reach wireless data speeds of up to 2.4 Gb/s with compatible devices. The X570 Tomahawk WIFI also delivers deep and immersive 5.1-channel surround sound through the Realtek ALC1200 audio codec. You can customize your computing experience using the RGB headers to connect light strips, which can be synced with MSI Mystic Light-compatible peripherals such as mice and keyboards.
