MSI B850M Gaming Wifi6E AMD Gaming Motherboard
- CPU: Ryzen 9000/8000/7000 AM5
- Memory: DDR5 8200+ MT/s, 7+2+1 Power
- Network: WiFi 6E, 2.5G LAN, PCIe 4.0
- Cooling: Gen5 M.2, Frozr Guard, Audio Boost
Product Pricing
EMI Start From*
SPECIFICATIONS
Processor
AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
AMD B850
Mainboard
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Memory
2x DDR5 UDIMM, Maximum Memory Capacity 128GB
Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen 9000 Series Processors max. overclocking frequency:
1DPC 1R Max speed up to 8200+ MT/s
1DPC 2R Max speed up to 8000+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only
Storage
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices
4x SATA 6G
M2_1 slot
Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)
M2_2 slot
Supports up to PCIe 4.0 x4
Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
Graphics
1x HDMI
Support HDMI 2.1, maximum resolution of 4K 60Hz
1x DisplayPort
Support DisplayPort 1.4, maximum resolution of 4K 60Hz
Networking & Connectivity
Realtek 8125D 2.5G LAN
Wi-Fi 6E Solution
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
5.3, FIPS, FISMA
Audio & Microphone
Realtek ALC897
7.1-Channel High Definition Audio
Ports
1x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E1 slot
Supports PCIe 4.0 x16 (For Ryzen 9000/ 7000 Series processors)
Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors)
Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor)
1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
3x System Fan
1x EZ Conn-header (JAF_1)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
2x USB 2.0 (Rear)
4x USB 2.0 (Front)
3x USB 5Gbps Type A (Rear)
1x USB 5Gbps Type C (Rear)
2x USB 5Gbps Type A (Front)
1x USB 10Gbps Type C (Front)
Software
Support for Windows 11 64-bit
Others
4x EZ Debug LED
1x EZ Memory Detection LED
Physical Specification
1.5KG
Warranty Information
3 Years
DESCRIPTION
MSI B850M Gaming WiFi6E AMD Gaming Motherboard Price in BD
The MSI B850M Gaming WiFi6E AMD Gaming Motherboard is built for gamers and PC enthusiasts seeking reliable performance, advanced connectivity, and future-ready compatibility. Designed for AMD Ryzen™ 9000, 8000, and 7000 Series desktop processors with the AM5 socket, this motherboard delivers exceptional performance for gaming, streaming, and productivity. It supports dual-channel DDR5 memory at speeds up to 8200+ MT/s via overclocking, enabling faster multitasking and improved system responsiveness. The robust 7+2+1-phase power design, Core Boost technology, and high-quality 6-layer PCB with 2oz copper enhance stability under demanding workloads. It also features WiFi 6E, 2.5G LAN, PCIe 4.0, Lightning Gen5 x4 M.2, Front USB Type-C, and Frozr Guard cooling for efficient thermal performance. Customers looking for the MSI B850M Gaming WiFi6E AMD Gaming Motherboard can purchase it from Tech Land BD at the best price in BD with genuine products and dependable customer support.
Why Buy the MSI B850M Gaming WiFi6E AMD Gaming Motherboard From Tech Land BD?
Choose the MSI motherboard category from Tech Land BD for dependable gaming performance, premium build quality, and advanced connectivity features. MSI motherboards are designed to support modern AMD processors, high-speed DDR5 memory, and next-generation storage technologies, making them an excellent choice for gamers, content creators, and professionals. Shop confidently at Tech Land BD to enjoy competitive prices, authentic products, and reliable after-sales service.
Which processors are compatible with this motherboard?
It supports AMD Ryzen™ 9000, 8000, and 7000 Series desktop processors using the AM5 socket.
Does this motherboard include built-in wireless connectivity?
Yes. It features integrated WiFi 6E and 2.5G LAN for fast, stable, and secure networking.
Does it support high-speed DDR5 memory and Gen5 SSDs?
Yes. The motherboard supports DDR5 memory up to 8200+ MT/s through overclocking and includes a Lightning Gen5 x4 M.2 slot for high-performance NVMe SSDs.
