MaxGreen MG-LI-EAP-850VA Offline UPS Specification
|
Main Features
| - Capacity :850VA
- Input Voltage: 220Vac
- Output Voltage: 220Vac
- Frequency (Battery Mode): 50Hz ± 1Hz
- Noise Level: Less than 40dB
- Indications: Line Mode Green lighting ,Battery Mode Yellow Lighting ,Fault Red Lighting
|
Battery
| - Internal maintenance-free lead-acid (12V/9Ah*1)
|
Alarm
| - Battery mode- Sounding every 10 seconds
- Low battery- Sounding every 10 seconds
- Overload -Sounding every 10 seconds
- Battery Replacement -Alarm Sounding every 10 seconds
- Fault- Continuously sounding
|
Output Features
| - Backup Time: up to 30 minutes
- Type of Wave: Simulated Sine Wave (Bat Mode)
- Voltage Range: 140-290VAC
|
Input Features
| - Frequency 50 Hz
- Voltage Range 140-290VAC
|
MaxGreen MG-LI-850VA Offline UPS
MaxGreen MGBK850LI UPS offline capacity 850 VA / 480 W Input voltage 220 VAC Input voltage range 140 290 VAC Frequency range 50 Hz Output voltage 220 VAC AC voltage regulation ± 10% (Bat mode) Frequency range 50 Hz ± 1 Hz (Bat mode) Transmission time Typical simulated sine wave in 26 ms waveform (bat mode).Battery type and number 12V / 9Ah * 1. Net weight (kg) 4.2 4. Dimensions, D * W * H (mm) 297X101X142. Typical charging time 46 hours recovery at 90 ° capacity Total protection short circuit, overload, battery discharge and overcharge, Overvoltage protection Humidity 090% Relative humidity 040 ℃ (non-condensing) Noise level Below 40 dB Optional USB / RS232 connection Compatible with Windows 2000/2003 / XP / Vista / 2008, Windows 7/8 Linux Unix and MAC.
