| Stock Status | Out Of Stock |
| Product ID | 7818 |
| Brand | Gigabyte |
| Product model | H370 D3H |
| Warranty | 3 years |
| Total Reviews | Based on 0 reviews. - Write a review |
| Mainboard | |
| Chipset | Intel® H370 Express Chipset |
| Memory | |
| Memory | Maximum Mamory: 64 GB Support for DDR4 2666/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules * To support 2666 MHz or XMP memory, you must install an 8th Generation Intel® Core™ i7/i5 processor. |
| Storage | |
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x2 SSD support) (M2P_16G) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2Q_32G) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors. Intel® Optane™ Memory Ready |
| Graphics | |
| Graphics | Integrated Graphics Processor-Intel® HD Graphics support: Support for AMD Quad-GPU CrossFireX™ and 2-Way AMD CrossFire™ technologies |
| Audio & Microphone | |
| Audio | Realtek® ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Networking & Connectivity | |
| LAN | Intel® GbE LAN chip (10/100/1000 Mbit) |
| Ports | |
| Slots | 4 x DDR4 DIMM sockets supporting |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 3 x system fan headers 1 x RGB LED strip header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper |
| USB | 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) * The CNVi connector shares bandwidth with the F_USB2 header. When a Wi-Fi module is populated in the CNVi connector, one of the USB 2.0/1.1 ports routed to the F_USB2 header becomes unavailable. |
| HDMI | 1 x HDMI port |
| Technical Info | |
| BIOS | 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Physical Specification | |
| Form Factor | Micro ATX Form Factor; 24.4cm x 23.0cm |
| Warranty Information | |
| Warranty | 3 years warranty |
GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential.The H370 Platform supports Intel’s latest Optane technology. Optane fuels storage performance by acting as a cache drive giving users a significant boost compared to traditional mechanical drives.
●︎ Supports 8th Gen Intel® Core™ Processors
●︎ Dual Channel Non-ECC Unbuffered DDR4
●︎ New Hybrid Digital PWM Design
●︎ Intel® CNVi 802.11ac Wave2 2T2R WIFI upgradable
●︎ High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
●︎ Dual Ultra-Fast M.2 with PCIe Gen3 X4/X2 & SATA interface
●︎ RGB FUSION supports RGB LED strips in 7 colors
●︎ Intel® Native USB 3.1 Gen 2 with USB Type-C™ andType-A
●︎ Intel® GbE LAN with cFosSpeed Internet Accelerator Software
●︎ CEC 2019 Ready, Save the Power as Easy as One Click
●︎ Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with ●︎ FAN STOP
●︎ Anti-Sulfur Resistors Design
●︎ Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection
●︎ Intel® Optane™ Memory Ready
