GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD - 1
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD - 2
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD - 3
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD - 4
GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD - 5

GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD

0 Reviews
Stock : Out of Stock
PID : P0392506280
Brand : Gigabyte
Model : B760M DS3H AX DDR4
Warranty : 3 Years
  • Chipset: Intel® B760 Express Chipset
  • Supported CPU: LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and C...
  • LAN: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • WiFi: Wireless Communication module AMD Wi-Fi 6E RZ608 (MT7921K) (For PCB rev. 1.0) WIFI a, b, g...

Product Pricing

Discount Price

৳17,700 ৳19,600
+ Available Payment Method

EMI Start From*

৳623

SPECIFICATIONS

Processor

Supported CPU LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™,
Pentium® Gold and Celeron® Processors
L3 cache varies with the CPU

Mainboard

Chipset Intel® B760 Express Chipset
BIOS 1 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory Support for DDR4 5333(O.C.)/
5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/
3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules

4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

Storage

Supported Storage CPU:

1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)

Chipset:

1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)

4 x SATA 6Gb/s connectors

RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices

Graphics

Graphics 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.0 version and HDCP 2.3.

1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

* Support for DisplayPort 1.2 version and HDCP 2.3

1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

* Support for DisplayPort 1.2 version.

Networking & Connectivity

LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
WiFi Wireless Communication module
AMD Wi-Fi 6E RZ608 (MT7921K) (For PCB rev. 1.0)

WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
LUETOOTH 5.2

Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)

WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
BLUETOOTH 5.3
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Intel® Wi-Fi 6E AX211 (For PCB rev. 1.2)
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands

BLUETOOTH 5.3

Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Realtek® Wi-Fi 6E RTL8852CE (For PCB rev. 1.3)

WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
BLUETOOTH 5.3

Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate

Audio & Microphone

Audio Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel

* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out

Ports

Slots CPU:

1 x PCI Express x16 slot, supporting
PCIe 4.0 and running at x16

Chipset:

2 x PCI Express x1 slots, supporting
PCIe 3.0 and running at x1
Internal I/O Ports 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

3 x system fan headers

1 x addressable LED strip header

1 x RGB LED strip header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

1 x S/PDIF Out header

1 x Q-Flash Plus button

1 x reset button

1 x reset jumper

1 x Clear CMOS jumper
External I/O Ports 2 x USB 2.0/1.1 ports

1 x PS/2 keyboard/mouse port

2 x SMA antenna connectors (2T2R)

1 x HDMI port

2 x DisplayPorts

3 x USB 3.2 Gen 1 ports

1 x USB Type-C® port, with USB 3.2 Gen 2 support

1 x RJ-45 port

3 x audio jacks
USB Chipset:

1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support

5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)

2 x USB 2.0/1.1 ports on the back panel
Chipset+2 USB 2.0 Hubs:

4 x USB 2.0/1.1 ports available through the internal USB headers
HDMI 1 x HDMI port

Software

Software Features Norton® Internet Security (OEM version)

LAN bandwidth management software

Special Features

Special Features Support for GIGABYTE Control Center (GCC)

* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Support for Q-Flash

Support for Q-Flash Plus

Others

Other Features I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection
Fan fail warning

Fan speed control

* Whether the fan speed control function is supported will depend on the cooler you install.

Physical Specification

Form Factor Micro ATX
Dimension 24.4cm x 24.4cm

Warranty Information

Warranty 3 Years

DESCRIPTION

GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD in Bangladesh


The GIGABYTE B760M DS3H AX DDR4 Motherboard is ideal for your high-performance PC. This motherboard provides exceptional computing performance by supporting 13th and 12th Generation Intel® CoreTM, Pentium® Gold, and Celeron® Processors. This motherboard provides enough memory capacity for demanding applications thanks to an Intel® B760 Express chipset and support for DDR4 memory modules with speeds of up to 5333 MT/s.


This motherboard supports up to triple-display with 1 HDMI, 2 DisplayPorts, and resolutions up to 4096x2304@60 Hz with integrated graphics. The Realtek® Audio CODEC supports 2/4/5.1/7.1-channel high-definition audio, while the Realtek® 2.5GbE LAN chip and Wi-Fi 6E support assure fast and stable internet access.


There are also multiple extension slots on the motherboard, including one PCI Express x16 port, two PCI Express x1 slots, and M.2 connections for high-speed storage. The USB Type-C® port, 5 USB 3.2 Gen 1 connections, and 4 SATA 6Gb/s connectors provide you plenty of alternatives for connecting your devices. SATA storage device RAID 0, RAID 1, RAID 5, and RAID 10 capabilities ensure data protection and high transfer speeds.


Finally, the GIGABYTE B760M DS3H AX DDR4 Motherboard is a high-performance motherboard with cutting-edge features and strong connection choices, making it an excellent choice for demanding applications and gaming.

REVIEWS

Login to write a review.

No reviews yet

Be the first to share your thoughts about this product.

What is the GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD Price in Bangladesh 2026 ?

The Gigabyte B760M DS3H AX DDR4 Price in BD is 17,700৳ . This GIGABYTE B760M DS3H AX DDR4 13TH GEN Micro ATX MOTHERBOARD Manufacturing by Gigabyte Comes With 3 Years Warranty & Based on 0 reviews. Tech Land BD Offers you Gigabyte B760M DS3H AX DDR4 by 17,700৳ and its regular price is 19,600৳ Which is also Out of Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
