| Stock Status | Up Coming |
| Product ID | 30402 |
| Brand | Gigabyte |
| Product model | B660M D2H DDR4 |
| Warranty | 3 years |
| Total Reviews | Based on 0 reviews. - Write a review |
| Processor | |
| Supported CPU | LGA1700 socket: Support for 13th Generation Intel® Core™ Processors and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors* L3 cache varies with CPU |
| Mainboard | |
| Chipset | Intel B660 Express Chipset |
| Memory | |
| Memory | Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/3000/2933/2666/2400/2133 MHz memory modules 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Storage | |
| Supported Storage | Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors |
| Graphics | |
| Graphics | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
| Audio & Microphone | |
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Networking & Connectivity | |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Ports | |
| Slots | 1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 4.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 3.0 standard.) |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.2 Gen 1 header 3 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x serial port header 1 x Q-Flash Plus button 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper |
| USB | Chipset: 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Technical Info | |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Physical Specification | |
| Form Factor | Micro ATX Form Factor; 22.5cm x 24.4cm |
| Warranty Information | |
| Warranty | 03 Years |
Experience a new level of computing with the GIGABYTE B660M D2H DDR4 motherboard. Designed to support 13th/12th Gen Intel® Core™ series processors, this motherboard delivers unrivaled performance for all your computing needs. Whether you're a gamer, content creator, or professional, this motherboard is built to exceed your expectations.
Next-Level Memory Performance and Expansion Options
With dual channel non-ECC unbuffered DDR4 and 2 DIMM slots, the GIGABYTE B660M D2H DDR4 motherboard offers lightning-fast memory performance. Unlock the full potential of your RAM and enjoy seamless multitasking, faster load times, and smoother overall system performance. Experience lightning-fast storage with the dual ultra-fast NVMe PCIe 4.0 x4 M.2 slots. Install your operating system, games, and applications on high-speed SSDs for near-instantaneous boot times and quick file transfers.
Immersive Gaming and Networking
Immerse yourself in the world of gaming with the GIGABYTE B660M D2H DDR4 motherboard. Featuring a fast 2.5 GbE gaming LAN with bandwidth management, you can enjoy smooth online gaming with reduced latency and lag. Say goodbye to network bottlenecks and gain the competitive edge in your favorite multiplayer games.
Unleash Your Creativity with RGB Fusion 2.0
Express your style and create a visually stunning PC setup with the RGB Fusion 2.0 technology. The GIGABYTE B660M D2H DDR4 motherboard supports addressable LED and RGB LED strips, allowing you to customize your lighting effects and synchronize them with other compatible devices for an immersive visual experience.
Advanced Cooling and Audio Solutions
Stay cool and quiet under intense workloads with Smart Fan 6 features, which include multiple temperature sensors and hybrid fan headers with fan stop. Enjoy a well-cooled system without compromising on noise levels. BImmerse yourself in high-quality audio with the high-quality audio capacitors and audio noise guard. Whether you're gaming, watching movies, or listening to music, the GIGABYTE B660M D2H DDR4 motherboard delivers crystal-clear sound for an immersive audio experience.
Upgrade Without Hassle
With the Q-Flash Plus feature, you can update the BIOS of your motherboard without the need to install the CPU, memory, and graphics card. This convenient feature saves you time and effort, ensuring that you always have the latest firmware to optimize your system's performance and compatibility.
Conclusion: Upgrade to the GIGABYTE B660M D2H DDR4 Motherboard
Unleash the full potential of your PC with the GIGABYTE B660M D2H DDR4 motherboard. Designed for performance, reliability, and expandability, this motherboard is the perfect choice for gamers, content creators, and professionals alike. Upgrade your system today and experience a whole new level of computing power.
