Name: GIGABYTE B560M DS3H V2 10TH AND 11TH GEN MICRO ATX MOTHERBOARD
Brand: Gigabyte
Availability: OutOfStock

GIGABYTE B560M DS3H V2 10TH AND 11TH GEN MICRO ATX MOTHERBOARD

Out Of Stock

GIGABYTE B560M DS3H V2 10TH AND 11TH GEN MICRO ATX MOTHERBOARD
Stock Status	Out Of Stock
Product ID	25052
Brand	Gigabyte
Product model	B560M DS3H V2
Warranty	3 years
Total Reviews	Based on 0 reviews. - Write a review

Based on 0 reviews. - Write a review

Out Of Stock

Add to Wish List Compare this Product

Product Information Declaimer

Stock availability is subject to change. Please confirm availability before shopping by calling us.
The product image is for illustration purposes only. The actual product may vary in size, color, and layout. No claim will be accepted for an image mismatch.
Tech Land BD can change the price of any product at any moment due to the volatile price of the technology.
We cannot guarantee that the information on this page is 100% correct. Tech Land BD is not responsible for the results obtained from the use of this information.

Processor
Supported CPU	11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors* * Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family. L3 cache varies with CPU
Mainboard
Chipset	Intel B560 Express Chipset
Memory
Memory	11th Generation Intel® Core™ i9/i7/i5 processors: Support for DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz 10th Generation Intel® Core™ i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz memory modules 10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors: Support for DDR4 2666/2400/2133 MHz memory modules 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Storage
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)(Note) Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB) 6 x SATA 6Gb/s connectors
Graphics
Graphics	1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz * Support for HDMI 1.4 version and HDCP 2.3. (Graphics specifications may vary depending on CPU support.)
Audio & Microphone
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
Networking & Connectivity
LAN	Realtek GbE LAN chip (1 Gbps/100 Mbps)
Ports
Slots	1 x PCI Express x16 slot, running at x16 (The PCIEX16 slot conforms to PCI Express 4.0 standard.)(Note) 2 x PCI Express x1 slots (The PCIEX1 slot conforms to PCI Express 3.0 standard.)
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 6 x SATA 6Gb/s connectors 2 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button
External I/O Ports	2 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x DisplayPort 1 x HDMI port 3 x USB 3.2 Gen 1 ports 1 x USB Type-C® port, with USB 3.2 Gen 1 support 1 x RJ-45 port 3 x audio jacks
USB	Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+USB 2.0 Hub: 2 x USB 2.0/1.1 ports available through the internal USB headers
Technical Info
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Physical Specification
Form Factor	Micro ATX Form Factor
Dimension	24.4cm x 24.4cm
Warranty Information
Warranty	3 years

Gigabyte B560M DS3H V2 Motherboard in Bangladesh

Whether you are looking to build a business-level machine or a budget-friendly gaming rig, the GIGABYTE B560M DS3H V2 LGA 1200 Micro-ATX Motherboard gives you the robust functionality found within larger boards in a compact design.

Based off the B560 chipset, this micro-ATX motherboard provides you with access to an LGA 1200 socket, allowing you to equip your rig with 10th and 11th Gen Intel processors. Install up to 128GB of DDR4 RAM with four dual-channel DIMM slots and install up to two PCIe NVMe solid-state drives, enhancing the overall speed of your system suitable for gaming or running multiple applications simultaneously. Six SATA III ports allow you to install an array of compatible drives for main or secondary storage systems. With one PCIe 4.0 x16 and two PCIe 3.0 x1 slots, you can install a wide range of graphics and utility cards designed to expand the flexibility of your system. USB 3.2 Gen 1 and USB 2.0 ports provide you with various connections for resource-demanding and low-powered peripherals, respectively. Additionally, a Gigabit Ethernet port is available, giving you quick access to wired networks so you can enjoy media, access company intranet, and take part in competitive online battles.
