Cooler Master MCB-D500D-KANN-S00 TD500 Mid Tower Case

MasterBox MB511 RGB

MESH FRONT PANEL

The mesh front panel offers efficient airflow for demanding systems.

PERFORMANCE INTAKE

Large intakes on each side of the front panel pay tribute to high performance cars.

RGB LED FANS AND LIGHTING CONTROL

Three 120mm RGB LED fans in front are pre-installed to create an amazing lighting effect. One RGB controller is included in the accessory pack. If your motherboard does not support the RGB control function, you can connect the RESET button and control the RGB lighting directly from the I/O panel.

EXCELLENT THERMAL PERFORMANCE

Optimized airflow due to the semi-meshed front panel and ventilation holes on top of the case.

FAN AND RADIATOR SUPPORT

    - Front: Three 120mm or two 140mm fans and up to a 360mm radiator with a maximum thickness of 50mm without fans.

    - Top: Two 120mm or two 140mm fans and supports a 120mm or a 240mm radiator.

    - Rear: One 120mm fan or radiator. All to ensure you don’t have to compromise on performance.

Cooler Master MCB-D500D-KANN-S00 TD500

●︎ Materials: Steel, Plastic

●︎ Dimensions (L x W x H): 493 x 217 x 468 mm

●︎ Motherboard: Support ATX (up to 272mm width), Micro-ATX, Mini-ITX

●︎ Expansion Slots: 7

●︎ 5.25″ Drive Bays: N/A

●︎ 3.5″ Drive Bays (HDD): 2 (Max. 2)

●︎ 2.5″ Drive Bays (SSD): 4 (Max. 6)

●︎ I/O Panel: USB 3.0 x 2, Audio In / Out

●︎ RGB controller: RGB controller included

●︎ RGB cable: 1 to 5 Splitter Cable included

●︎ Pre-installed Fan(s): Front 120mm RGB Fan x 3

●︎ Rear 120mm Black: Fan x 1

●︎ Fan Support Front: 120mm x 3 / 140mm x 2

●︎ Top: 120/140mm x 2

●︎ Rear: 120mm x 1

●︎ Radiator Support Front: 120/140/240/280/360mm

●︎ Rear: 120mm

●︎ Top: 120/240mm

●︎ Clearances: CPU Cooler: 165mm / 6.49″

●︎ PSU: 180mm / 7.08″

●︎ GPU: 410mm / 16.10″

●︎ Cable Routing: Behind MB Tray: 19mm / 0.74″

●︎ Dust Filters: Front, Top, Bottom

●︎ Power Supply Support: Bottom mount, ATX
