TP-LINK TL-SG1008 SPECIFICATION |
Standards and Protocols
| - IEEE 802.3i
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3x
- IEEE 802.1p
|
Interface
| 8 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
|
Network Media
| - 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
|
Fan Quantity
| Fanless
|
Power Supply
| 100-240VAC, 50/60Hz
|
Power Consumption
| Maximum: 4.1W
|
Dimensions ( W x D x H )
| - 11.6 x 7.1 x 1.7 in.
- (294 x 180 x 44 mm)
|
Mounting
| 13" or 19" Rack Mountable
|
Max Power Consumption
| 4.3W
|
Max Heat Dissipation
| 14.67BTU/h
|
Switching Capacity
| 16Gbps
|
Packet Forwarding Rate
| 11.9Mpps
|
MAC Address Table
| 4K
|
Jumbo Frame
| 16KB
|
Transfer Method
| Store-and-Forward
|
Advanced Features
| - MAC addresses auto-learning and auto-aging
- IEEE802.3x Flow control
- 802.1p/DSCP QoS
|
TP-LINK TL-SG1008 8-PORT GIGABIT DESKTOP/RACKMOUNT SWITCH IN BANGLADESH
FEATURES
- 8 10/100/1000Mbps RJ45 ports
- Supports MAC address auto-learning and auto-aging and auto MDI/MDIX
- Standard 13-inch rackmount steel case (rackmount bracket for 19" mounting is included)
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
What This Product Does
The TL-SG1008 8-Port Gigabit desktop/rack-mount switch provides an easy way to make the transition to Gigabit Ethernet. All 8 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with innovative energy-efficient technology, the TL-SG1008 can save power consumption, making it an eco-friendly solution for your business network.
TP-LINK Green Technology
This new generation The 8-Port Gigabit Desktop/Rackmount Switch TL-SG1008 features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.
High Performance
The TL-SG1008 features non-blocking wire-speed architecture with a 16Gbps switching capacity for maximum data throughput. A 4K MAC address table provides scalability for even the largest networks. It also supports 802.3x Flow Control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission.
Ease to Use
The auto features of this gigabit switch make installation plug-and-play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminates the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. The compact size shell makes it ideal for desktops with limited space while it is also rack-mountable, convenient, and safe. Dynamic LED lights provide real-time work status display and basic fault diagnosis. TL-SG1008 features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
