Tp-Link T1500G-10MPS Jet Stream 8-Port Gigabit Smart Switch
Tp-Link T1500G-10MPS Smart Switch Overview
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad,IEEE 802.3x, IEEE 802.3az IEEE 802.1d, IEEE 802.1s, IEEE 802.1w,IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
| Interface | 8 10/100/1000Mbps RJ45 Ports, all supporting PoE+ 2 100/1000Mbps SFP Slots |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable 100BASE-TX/1000Base-T: UTP Category 5, 5e, or above cable |
| Fan Quantity | 1 |
| PoE+ Ports(RJ45) | Standard: 802.3at/af compliant PoE+ Ports: 8 Ports Power Supply: 116 W |
| Dimensions ( W x D x H ) | 11.6 x 7.1 x 1.7 in. |
| Mounting | Rack-Mountable |
| Power Consumption | 15.61W 139.52W |
| Max Heat Dissipation | 53.26 BTU/h 476.04 BTU/h |
| Bandwidth | 14.9Mpps |
| Packet Forwarding Rate | 41.7 Mpps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 512KB |
| MAC Address Table | 8K |
| Quality of Service | 802.1p CoS/ DSCP priority Support 8 priority queues Priority Schedule Mode SP (Strict Priority) |
| L2 Features | Loopback Detection |
| VLAN | VLAN Group 802.1Q tag VLAN MAC VLAN Protocol VLAN MAC/Protocol-based VLAN |
| Access Control List | L2–L4 package filtering MAC ACL Combined ACL |
| Certification | CE, FCC, RoHS |
| Security | AAA 802.1X IP/IPv6-MAC Binding IPv6 Source Guard DoS Defend |
| Package Contents | T1500G-10MPS Power Cord Installation Guide Resource CD |
| System Requirements | Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% Storage Humidity: 5–90% |
| Warranty | 1 Year |
Features 8 802.3af/at compliant PoE+ ports, with a total PoE power budget of 116W and useful PoE power management, features Gigabit Ethernet connections on all ports provide full speed of data transferring Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, and Radius Authentication L2/L3/L4 QoS and IGMP snooping optimize voice and video applications WEB/CLI managed modes, SNMP, RMON bring abundant management features. Dual Firmware Image improves reliability and uptime of your network
IEEE 802.3at/af-compliant Power over Ethernet
The T1500G-10MPS supports 8 ports of IEEE 802.3af/at-compliant PoE and has a total power supply of 116W to power any 802.3af/at-compliant power device. It’s an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones, and other PoE-supported devices, while getting rid of cables or power lines running around. Compact and flexible, the T1500G-10MPS is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks.
Advanced QoS features
To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supports, the voice application will operate with much smoother performance.
Abundant Layer 2 features
For more application of layer 2 switches, T1500G-10MPS supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, STP/RSTP/MSTP; Link Aggregation Control Protocol and 802.3x Flow Control function. Anymore, the switches provide advanced features for network maintenance such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP Snooping ensures the switch intelligently forwards the multicast stream only to the appropriate subscribers while IGMP throttling & ‑filtering restrict each subscriber on a port level to prevent unauthorized multicast access.
Enterprise Level Management Features
T1500G-10MPS is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface (GUI) or industry-standard Command Line Interface (CLI). SNMP (v1/2/3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events..
