TP-LINK EAP225 AC1350 Access Point Overview
Interface
| Gigabit Ethernet (RJ-45) Port x 1
|
Physical Security Lock
| Yes
|
Button
| Reset
|
Power Supply
| 802.3af/at PoE PoE or passive PoE
|
Power Consumption
| 12.6W
|
Dimensions ( W x D x H )
| 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
|
Dimensions
| × 7.1 × 1.5 in
|
Antenna Type
| 3 Internal Omni 2.4GHz: 4dBi 5GHz: 5dBi
|
Mounting
| Ceiling mount or wall mount
|
Wireless Standards
| IEEE 802.11ac/n/g/b/a
|
Frequency
| 2.4GHz and 5GHz
|
Signal Rate
| 5GHz: Up to 867Mbps 2.4GHz: Up to 450Mbps*
|
Wireless Functions
| Multiple SSIDs Enable/Disable Wireless Radio Transmit Power Control Seamless Roaming
|
Wireless Security
| Captive Portal Authentication Access Control 802.1X Support SSID to VLAN Mapping
|
Transmission Power
| ≤24dBm(2.4GHz) ≤22dBm(5GHz)
|
Omada App
| Yes
|
Centralized Management
| Omada Cloud-Based Controller Omada Hardware Controller Omada Hardware Controller Omada Software Controller
|
Email Alerts
| Yes
|
LED ON/OFF Control
| Yes
|
Access Control
| Yes
|
SNMP
| v1,v2c
|
System Logging Local/Remote Syslog
| Local/Remote Syslog
|
Telnet
| Yes
|
SSH
| Yes
|
Web-based
| HTTP/HTTPS
|
Certification
| FCC, RoHS
|
Package Contents
| EAP225 Passive PoE Adapter Power Cord Mounting Kit
|
Environment
| Operating Temperature Storage Temperature Operating Humidity Storage Humidity
|
Mounting
| Ceiling mount or wall mount
|
Warranty | 1 year |
TP-LINK EAP225 AC1350 Access Point in Bangladesh
Simultaneous 450Mbps1 on 2.4GHz and 867Mbps1 on 5GHz totals 1317Mbps1 Wi-Fi speeds EAP Controller Software lets administrators easily manage hundreds of EAPs. Compatibility with 802.3af and Passive PoE support makes deployment effortless and flexible. Captive portal provides a convenient method for guest authentication. Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections. MU-MIMO2 means access points simultaneously transfer data with multiple devices, speeding up connections. Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience. Supports management VLAN for an enhanced network management Schedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose.
Superior Wi-Fi Speeds with MU-MIMO Technology
Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.
Cloud Centralized Management- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Facebook check-in and SMS authentication expands your social influence in secure ways
The captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE injector, making deployment effortless and flexible.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status, and manage clients, all from the convenience of a smartphone or tablet.
