TOTOLINK SW804P 8-Port 10/100Mbps Ethernet Switch with 4-Port PoE
TOTOLINK SW804P 8-Port 10/100Mbps Ethernet Switch with 4-Port PoE
TOTOLINK SW804P 8-Port 10/100Mbps Ethernet Switch with 4-Port PoE - 1

TOTOLINK SW804P 8-Port 10/100Mbps Ethernet Switch with 4-Port PoE

0 Reviews
Stock : Discontinued
PID : P0782506008
Brand : TOTOLINK
Model : SW804P
  • External power supply
  • More power saving
  • Up to 15.4Watt PoE port
  • 4*10/100Mbps PoE Ports

DESCRIPTION

TOTOLINK SW804P 8-Port Ethernet Switch Overview

Standards
IEEE 802.3af
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
Interface
4*10/100Mbps PoE Ports
4*10/100Mbps auto-negotiation RJ-45 Ports
LED Indicators
1*Power,4*PoE,1*Overload,8* Link/Act
Dimensions
158.4mm x 106.5mm x 27mm
Port Lightning Protection
6KV
MAC Address Learning
Auto-Learning, Auto-Aging
MAC Address Table
1K
Network Media10BASE-T: UTP Cat 3 or above cable
100BASE-TX: UTP Cat 5, 5e or above cable
Backup Bandwidth
1.6Gbps
Transmission Method
Store-and-forward
PoE Supply Management
Port 1 to Port 4 support IEEE802.3at/af PoE standard
PoE Through Pin
1 2 4 5 +，3 6 7 8
Power Input
AC：100-240V～ 50/60Hz
DC : 48V /1.25A（Power Adapter )
Power Consumption
In full configuration：<63W
PoE Max Power Supply
58W
OthersOperating Temperature: 0℃~50℃ (32℉~122℉)
Storage Temperature: -40~70℃ (-40℉~158℉)
Operating Humidity: 5%~95% non-condensing
Storage Humidity: 5%~95% non-condensing
Warranty1 years

TOTOLINK SW804P 8-Port Ethernet Switch in Bangladesh

The SW804P is a 8-port 10/100Mbps Ethernet Switch with 4 portssupport Power over Ethernet(PoE). All these four ports can detect connected devices automatically and deliver power & data to all IEEE 802.3af compliant PoE powered devices through one Ethernet cable. SW804P supports plug-and-play and can also be simply connected to a server, a hub or a switch using straight cable or crossover cable. Complies with IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3x. 4*10/100Mbps PoE Ports, 4*10/100Mbps auto-negotiation RJ45 Ports. Up to 15.4Watt for each PoE port. LED indicators for monitoring power, PoE, overload status, link and activity. Metal case, desktop or wall-mounting design. External power supply. More power saving and higher performance.
