Hikvision DS-3E0326P-E-M 24 Port Fast Gigabit Ethernet Unmanaged PoE Manage Switch
Hikvision DS-3E0326P-E-M 24 Port Fast Gigabit Ethernet Unmanaged PoE Manage Switch-cover-thumbnail

Hikvision DS-3E0326P-E-M 24 Port Fast Gigabit Ethernet Unmanaged PoE Manage Switch

Stock : In Stock
PID : P0332506166
SKU : TEHVDS-326P-E-M-NS
Brand : Hikvision
Model : DS-3E0326P-E-M
Warranty : 1 Year
★ ★ ★ ★ ★
0 Reviews
  • Internal Cache: 2.75 Mbits
  • Switching Capacity: 8.8 Gbps
  • Packet Forwarding Rate: 6.547 Mpps
  • High Priority Ports: Ports 1 to 8

    • Discount Price

    ৳ 25,000 ৳ 29,500
    Available Payment Method

    EMI Start From*

    ৳ 880

    Hikvision DS-3E0326P-E-M PoE Switch Specification

    Network Parameters
    • Port Number: 24 × 10/100 Mbps PoE ports, 1 × gigabit RJ45 port, and 1 × gigabit fiber optical port
    • Port Type: RJ45 port, full duplex, MDI/MDI-X adaptive
    • Working Mode: Standard mode (default); Extend mode
    • Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
    • Forwarding Mode: Store-and-forward switching
    • Ports For Long-Distance Transmission: Ports 17 to 24
    • MAC Address Table: 4 K
    • Internal Cache: 2.75 Mbits
    • Switching Capacity: 8.8 Gbps
    • Packet Forwarding Rate: 6.547 Mpps
    • High Priority Ports: Ports 1 to 8
    PoE Power Supply
    • PoE Standard: IEEE 802.3af, IEEE 802.3at
    • PoE Power Pin: End-span: 1/2(-), 3/6(+); Mid-span: 4/5(+), 7/8(-); 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
    • PoE Port: Ports 1 to 24
    • Max. Port Power: 30 W
    • PoE Power Budget: 230 W
    Dialing Function
    		Long Range: Ports 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
    General
    • Dimension (W × H × D): 335 mm × 44.5 mm × 226 mm (13.2” × 1.8” × 8.9”)
    • Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
    • Storage Humidity: 5% to 95% (no condensation)
    • Gross Weight: 3.33 kg (7.34 lb)
    • Net Weight: 2.55 kg (5.6 lb)
    • Power Consumption In Idle: 20 W
    • Shell: Metal material
    • Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F)
    • Operating Humidity: 5% to 95% (no condensation)
    • Power Supply: 100 to 240 VAC, 50/60 Hz, Max. 4 A
    • Max. Power Consumption: 250 W
    Approval
    • EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
    • Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
    • Chemistry: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)


    Hikvision DS-3E0326P-E/M 24 Port Fast Gigabit Ethernet Unmanaged PoE Manage Switch in Bangladesh


    Features

    • Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
    • Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
    • 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
    • 6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
    • Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.
