Grandstream GWN7812P 16 Port Layer 3 Gigabit Managed PoE Switch

Grandstream GWN7812P 16 Port Layer 3 Gigabit Managed PoE Switch

0 Reviews
Stock : Up Coming
PID : P3032506098
Brand : Grandstream
Model : GWN7812P
Warranty : 1 Year
  • Ports: 16x GE, 4x 10G SFP+
  • Switching: 112Gbps
  • PoE: 30W per port, 240W total
  • Forwarding: 83.328Mpps

SPECIFICATIONS

Networking & Connectivity

Advanced Functions Built-in QoS allows for prioritization of network traffic

Embedded controller to manage switch; GWN. Cloud and GWN Manager,
Grandstream’s cloud and on-premise network management platform

ARP Inspection, IP Source Guard, DoS protection, port security & DHCP
snooping
Network Standard IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z,
IEEE 802.3ae, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE
802.1d, IEEE 802.1s, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3AB, IEEE
802.1p, IEEE 802.1D, IEEE 802.1x
Transmission Method Forwarding Mode: Store-and-forward
MAC Address Table 16K static, dynamic and filtering MAC addresses

4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN

VLAN virtual interface

GVRP (pending)

Spanning tree, 32 instances for STP/RSTP/MSTP

Battery And Power

Power Supply 30W Max Output Power per PoE Port

120W Max Total PoE Output Power

Ports

Port 8x Gigabit Ethernet Ports

2x 10Gigabit SFP+ Ports

Physical Specification

Temperature Operation: 0°C to 45°C

Storage: -10°C to 60°C
Humidity 10% to 90% RH(Non-condensing)

10% to 90% RH(Non-condensing)
Dimension 330mm(L)x176mm(W)x44mm(H)
Weight 2.17Kg

Technical Info

LED Indicators 1x tri-color LED for device tracking and status indication

8x yellow-color LEDs
Data Transmission Rate Switching Capability: 56Gbps

Total non-blocking throughput: 28Gbps

Forwarding Rate: 41.644Mpps

Packet Buffer: 12Mb

Network Latency: <4µs
Type Layer 3 PoE Managed Switch

Warranty Information

Warranty 1 Year

DESCRIPTION

Grandstream GWN7812P 16 Port Layer 3 Gigabit Managed PoE Switch in BD


Specifications

The Grandstream GWN7812P is a robust Layer 3 PoE Managed Switch designed to deliver high performance and advanced networking features. It comes equipped with 16x Gigabit Ethernet Ports and 4x 10Gigabit SFP+ Ports, making it suitable for handling intensive network traffic. This switch supports a comprehensive range of network standards, including IPv4, IPv6, and various IEEE protocols, ensuring seamless integration into diverse networking environments. The device features built-in QoS for traffic prioritization and an embedded controller for efficient switch management. Enhanced security features like ARP Inspection, IP Source Guard, DoS protection, port security, and DHCP snooping are also included. Operating on a store-and-forward transmission method, the GWN7812P boasts a switching capability of 112Gbps, total non-blocking throughput of 56Gbps, and a forwarding rate of 83.328Mpps. The switch also offers a 12Mb packet buffer and network latency of less than 4µs for optimal data handling.


Availability and Usability

The Grandstream GWN7812P is readily available at Tech Land BD, your go-to destination for high-quality networking solutions. This switch is perfect for businesses seeking to enhance their network infrastructure with a powerful, reliable, and secure device. Its PoE capabilities, providing a maximum output power of 30W per port and a total of 240W, make it ideal for powering a variety of devices such as IP cameras, phones, and access points. The extensive MAC address table and VLAN support allow for sophisticated network configurations, ensuring flexibility and scalability. The switch’s compact dimensions (440mm x 200mm x 44mm) and weight of 3.03Kg make it easy to install in various settings. With a 1-year warranty, customers can purchase with confidence, knowing they have access to reliable support and service.


Highlights

  • 16x Gigabit Ethernet Ports and 4x 10Gigabit SFP+ Ports
  • PoE with 30W per port and 240W total output
  • Switching capability of 112Gbps and low network latency
  • Built-in QoS and advanced security features
  • Available at Tech Land BD with a 1-year warranty


Secure Your Grandstream GWN7812P at Tech Land BD Today

Upgrade your network infrastructure with the Grandstream GWN7812P 16 Port Layer 3 Gigabit Managed PoE Switch from Tech Land BD. This high-performance switch offers advanced security features, extensive connectivity, and reliable power delivery for your critical devices. Don’t miss out on the chance to enhance your network’s efficiency and security. Visit Tech Land BD now to secure your Grandstream GWN7812P and ensure the best value and support for your investment.
