| Stock Status | Out Of Stock |
| Product ID | 28373 |
| Brand | Gigabyte |
| Product model | RTX 3060 GAMING OC |
| Warranty | 2 Years |
| Total Reviews | Based on 0 reviews. - Write a review |
| Memory | |
| Memory Size | 8 GB |
| Memory Type | GDDR6 |
| Memory Bandwidth (GB/sec) | 240 GB/s |
| Memory Clock | 15000 MHz |
| Memory Bus (Bit) | 128 bit |
| Display | |
| Resolution | 7680x4320 |
| Multi Display | 4 |
| Graphics | |
| Graphics Chipset | GeForce RTX 3060 |
| CUDA Cores (Nvidia) | 3584 |
| Core Clock | 1807 MHz (Reference Card: 1777 MHz) |
| Interface (PCI Express) | PCI-E 4.0 |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Battery And Power | |
| Recommended Power | 550W |
| Power Connector | 8 pin*1 |
| Ports | |
| Ports & Connectors | DisplayPort 1.4a *2 HDMI 2.1 *2 |
| Physical Specification | |
| Card Size | L=198 W=121 H=39 mm |
| Warranty Information | |
| Warranty | 2 years |
The WINDFORCE 2X cooling system features two 90mm unique blade fans, alternate spinning, 3 composite copper heat pipes direct touch GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
The GIGABYTE “Alternate Spinning” is the only solution that can solve the turbulent airflow of adjacent fans. Since the adjacent fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
