DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier
DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier-cover-thumbnail DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier-1

DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier

Stock : In Stock
PID : P6452506057
Brand : DSPPA
Model : PAVA8500E
Warranty : 01 Year
★ ★ ★ ★ ★
0 Reviews
  • Power Output: ≥500W (100V)
  • Frequency Response: 50Hz–18kHz
  • Signal to Noise Ratio: >80dB (Line)
  • Working Power: AC 220–240V / DC 24V

    • Discount Price

    ৳ 129,900 ৳ 135,900
    Available Payment Method

    EMI Start From*

    ৳ 4,574

    DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier in Bangladesh

    The DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier is a powerful and reliable solution designed for expanding large-scale voice evacuation and public address systems. With a rated output power of ≥500W (100V), it delivers robust and clear audio across up to eight zones, making it ideal for commercial buildings, transportation hubs, schools, and industrial facilities. This amplifier ensures high performance with both emergency mic and line inputs, offering excellent input sensitivity (5 mV/600 Ω for emergency mic and 1000 mV/10 kΩ for line) and maintaining harmonic distortion at less than 1% at 1 kHz. The frequency response range covers 80 Hz–15 kHz for the emergency mic and 50 Hz–18 kHz for the line input, providing crystal-clear, full-range sound reproduction. With a superior signal-to-noise ratio of >75dB (emergency mic) and >80dB (line), the PAVA8500E guarantees minimal background noise for crisp communications. The system features robust control capabilities, including system fault relay outputs, emergency mode relay outputs, and 8 dry contact inputs and outputs, all operating in a short-circuit, no-voltage mode for secure and reliable signal transmission. It also supports level mode inputs from 3.3V to 24V. Integrated voice message management utilizes WAV files stored on an SD card, with data retention exceeding 10 years, ensuring readiness in critical moments. Designed for resilience, the PAVA8500E operates on both AC 220–240V and DC 24V/30A, with low voltage protection (20±1V) to maintain system stability. Its battery system supports a rated charging current of 3.8A and a maximum amplified current of 5A, ensuring uninterrupted operation during power outages. The amplifier is housed in a durable and compact chassis (483×420×132mm) and is packaged securely (550×510×215mm) for transport and installation. Built to meet the demands of modern safety and communication standards, the DSPPA PAVA8500E provides an essential extension for comprehensive voice evacuation systems, combining power, clarity, and reliability in one integrated solution.

    FAQs:


    1. Can the PAVA8500E operate during a power outage?

    Yes, the PAVA8500E is designed to operate on both AC 220–240V and DC 24V/30A. It includes battery charging and low-voltage protection features to ensure the system remains active during power failures, providing continuous voice alarm and PA services.

    2. What types of input signals does the PAVA8500E support?

    The PAVA8500E supports emergency microphone inputs (5 mV, 600 Ω) and line inputs (1000 mV, 10 kΩ). It delivers high-fidelity sound with less than 1% harmonic distortion at 1 kHz for both input types, ensuring clear and reliable communication.

    3. How does the PAVA8500E connect and communicate with other system components?

    The amplifier features 8 dry contact inputs and outputs, along with system fault and emergency mode relay outputs, all operating through short-circuit, no-voltage control. This setup guarantees stable and fast interaction with the main PA system for quick emergency responses.

    What is the DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier Price in Bangladesh 2025 ?

    The DSPPA PAVA8500E Price in BD is 129,900৳ . This DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier Manufacturing by DSPPA Comes With 01 Year Warranty & Based on 0 reviews. Tech Land BD Offers you DSPPA PAVA8500E by 129,900৳ and its regular price is 135,900৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
