DSPPA DSP602EN 6.5 Inch Fireproof Ceiling Speaker

DSPPA DSP602EN 6.5 Inch Fireproof Ceiling Speaker in Bangladesh

The DSPPA DSP602EN is a high-quality 6.5-inch fireproof ceiling speaker designed for voice alarm and public address systems in emergency scenarios. Built to comply with EN54-24:2008 standards for voice alarm systems in fire detection and alarm setups, this speaker is ideal for indoor public buildings, offices, schools, hospitals, and commercial spaces. With a 1-way, double-cone, full-range speaker (Ø156mm), the DSP602EN ensures clear and intelligible voice communication, making it a reliable choice for emergency announcements. Operating on a 100V system, it comes with a built-in transformer supporting 6W, 3W, and 1.5W power taps, allowing flexible installation based on different area coverage requirements. The frequency response of 90 Hz–18 kHz (±7 dB) ensures balanced sound reproduction, while its 91 dB sensitivity (@1 m, 1 W) provides excellent audibility even in challenging environments. The speaker delivers a maximum sound pressure level (SPL) of 99 dB (@1m, Pmax), ensuring loud and clear performance. With a wide coverage angle of 180° at 1 kHz, it effectively distributes sound evenly across a large space. Safety is a priority with the DSP602EN, featuring flame-retardant ABS housing, a ceramic connector, and a thermal fuse to ensure reliability in high-temperature conditions. Its IP21C protection rating makes it suitable for indoor installations where fire safety compliance is essential. The speaker is designed for easy ceiling integration with a compact size of Ø190mm and a depth of 108mm, requiring a hole diameter of Ø168-172mm for installation. Weighing just 1.0kg, it is lightweight yet durable, ensuring long-term performance without compromising structural integrity. The DSPPA DSP602EN is the perfect solution for buildings requiring a certified fireproof ceiling speaker that meets stringent safety standards while delivering high-quality sound for emergency and public address applications. Its reliability, superior audio clarity, and compliance with EN54-24 make it an essential component in modern voice evacuation and public announcement systems.

FAQs:

1. Is the DSP602EN certified for fire alarm and evacuation systems?

Yes, the DSP602EN complies with the EN54-24:2008 standard for loudspeakers used in voice alarm systems for fire detection and alarm systems.

2. What is the power rating, and how can it be adjusted?

The DSP602EN operates on a 100V line and supports selectable power taps of 6W, 3W, and 1.5W through its built-in transformer.

3. What safety features does the DSP602EN include?

It is constructed with flame-retardant ABS material and is equipped with a ceramic connector and thermal fuse to ensure safe operation during fire conditions.
