DJI Ronin SC2 3-Axis Gimbal Overview
Peripheral
| - Accessory Connections 1/4” Mounting Hole, 3/8” Mounting Hole, Camera Control Port, Accessory Port, USB-C Port, RSA Port
- Intelligent Battery Model: RB2-2450mAh-7.2V
- Type: 18650 LiPo
- Capacity: 2450 mAh
- Power: 17.64 Wh
- Max. Battery Life: 11 h
- Charging Time: 2.5 h (5 V/2 A)
- Charging Temperature: 5° to 40°C (41° to 104°F)
- Connections Bluetooth 5.0; USB-C
- Mobile Assistant Software Requirements iOS 9 or above; Android 5.0 or above
|
Working Performance
| - Tested Payload ≤ 2.0 kg
- Angular Vibration Range ±0.02°
- Maximum Controlled Rotation Speed Pan axis control: 180°/s
- Tilt axis control: 180°/s
- Roll axis control: 180°/s
- Mechanical Endpoint Range Pan axis control: 360° continuous rotation
- Tilt axis control: -202.5° to +112.5°
- Roll axis control: -95° to +220
- Controlled Rotation Range Pan axis control: 360° continuous rotation
- Tilt axis control: -90° to 145°
- Roll axis control: ±30°
|
Mechanical & Electrical Characteristics
| - Working Current Static current: 0.2 A
- Working Frequency 2.400 GHz to 2.4835 GHz
- Transmission Power ≤ 8 dBm
- Operating Temperature -20° to 45°C (-4° to 113°F)
- Weight Gimbal: Approx. 830 g
- BG18 Grip: Approx. 258 g
- Tripod: Approx. 160 g
- Gimbal Dimensions Folded: 220×200×75 mm
- Unfolded: 370×165×150 mm
|
DJI Ronin SC2 3-Axis Gimbal in Bangladesh
With a lightweight design and superior stabilization, Ronin-SC is a 3-axis stabilizer for mirrorless cameras, allowing users to create professional footage with ease.
Lightweight & Compact
Opening possibilities for filmmakers and content creators in almost any situation, Ronin-SC was built to go anywhere. Magnesium and aluminum construction, along with high-strength composite materials provide robust performance at just 1.1 kg. With a modular, quick setup design, Ronin-SC can pack neatly in limited spaces and be carried with ease.
Greater Compatibility
Ronin-SC supports a wide range of cameras and lenses while meeting strict performance standards. It has been rigorously tested to support a payload of 2.0 kg while still achieving a smooth, cinematic shot. Intuitive and user-friendly controls for shutter and focus are also available for most camera brands.
Dynamic Stability
Even in action-packed scenes, Ronin-SC gives a perfectly stable shot. Sport mode improves the sensitivity of each axis while continuing to maintain stabilization, making Ronin-SC more effective in fast follows, sudden motions, and even complete changes in direction.
Unobstructed Roll Axis Arm
An innovative framework elevates camera payload above the roll axis, keeping the camera's built-in display free of obstruction. After DJI introduced this concept, it has been embraced throughout the handheld gimbal industry.
Unobstructed Roll Axis Arm
An innovative framework elevates camera payload above the roll axis, keeping the camera's built-in display free of obstruction. After DJI introduced this concept, it has been embraced throughout the handheld gimbal industry.
Down to Every Detail
The buttons and trigger are easy to reach for every essential control. A flared battery grip makes extended holding easier and slip-resistant, letting you capture moments throughout the day.
Automated Features
Ronin-SC offers a suite of advanced capturing features to unleash your imagination.
ActiveTrack 3.0
ActiveTrack technology arrives for the first time in the Ronin series. A smartphone mounted above the camera, the Ronin app, and Ronin-SC work together seamlessly to achieve smooth, precise gimbal movement at all times, allowing you to focus more on creating the shot that matches your vision.
Force Mobile
Ronin-SC introduces Force Mobile, an app-based version of the Force Pro camera movement control system. By tilting and rotating your smartphone, users can control the gimbal with ultra-low latency, delivering a fluid, expressive shot with an instinctive feel.
Ronin App
The Ronin app has also been improved for an even better user experience making Ronin-SC professional and easy to use. The layout has been refined to offer quicker access to preset scenarios, and we’ve also included a camera balancing guide, along with tutorials to help users master their handheld gimbal. The app also minimizes hardware tuning, setting filmmakers free to produce great footage.
Simple Setup with Safety Features
Axis locks on each arm allow for faster storage and individual axis balancing. The Quick-Release Plate includes a positioning block to memorize the perfect camera position for instant remounting. When powering off, the motors gradually power down the gimbal, ensuring reliability and quick setup wherever your shot takes you.
An Ecosystem of Accessories
An ever-growing list of powerful accessories empowers Ronin-SC to push boundaries further and gives filmmakers the tools for endless imagination.
