Dahua DH-IPC-H5AE 5 MP Wi-Fi Pan With Tilt Network Camera
- Image Sensor 1/3.2" CMOS
- Max. Aperture 3.6 mm: F2.0
- Video Compression H.265
- Casing Material Plastic
Product Pricing
SPECIFICATIONS
Camera
1/3.2" CMOS
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Illumination Distance
Up to 10 m (32.81 ft) (IR)
Illuminator On/Off Control
Auto
Illuminator Number
1 (IR LED)
Angle Adjustment
Pan: 0° to 355°;
Tilt: -5° to +80°
3.6 mm: F2.0
Field of View
3.6 mm: H: 79°; V: 43°; D: 94°
Networking & Connectivity
RJ-45 (10/100 Base-T)
Wi-Fi
IEEE 802.11b/g/n 2.4–2.4835 GHz, 2.4 G
Storage
Micro SD card (up to 256 GB)
Management Software
DMSS
Mobile Client
iOS;Android
Audio & Microphone
Yes, built-in Mic
Built-in Speaker
Yes, built-in speaker
Audio Compression
G.711a
Battery And Power
5 VDC, 1A
Power Consumption
Basic: 1.7 W;
Max. (video stream acquiring + IR +
Video Features
H.265
Video Frame Rate
Main stream: 1920 × 1080 @25 fps
Sub stream: 640 × 480 @25 fps
Resolution
1080p (1920 × 1080); VGA (640 × 480)
Video Bit Rate
H.265: 80 kbps–4096 kbps
Day/Night
Auto(ICR)/Color/B/W
WDR
DWDR
Motion Detection
OFF/ON (4 areas, rectangular)
Image Rotation
0°/180°
Special Features
Physical Specification
–10 °C to +45 °C (+14 °F to +113 °F)
Operating Humidity
≤ 95%
Warranty Information
DESCRIPTION
Dahua DH-H5AE 5MP Camera in Bangladesh
The Dahua DH-H5AE 5MP Wi-Fi Pan & Tilt Network Camera, available at TechLand BD, is an excellent choice for those seeking reliable, high-quality surveillance for outdoor or indoor spaces. This camera boasts a 1/3.2" CMOS image sensor that captures clear and detailed images with a maximum resolution of 1920 x 1080 pixels. Its electronic shutter speed can be adjusted automatically or manually, ranging from 1/3 second to 1/100,000 seconds, ensuring optimal image capture under various lighting conditions. The camera's illumination distance extends up to 10 meters (32.81 feet) thanks to its single IR LED, providing clear night vision capabilities. The illuminator can be controlled automatically, enhancing convenience and performance. The Dahua DH-H5AE offers an impressive pan and tilt range, with 0° to 355° panning and -5° to +80° tilting, providing comprehensive coverage and flexibility for monitoring different areas. The lens has a maximum aperture of F2.0 at 3.6 mm, offering a field of view of 79° horizontally, 43° vertically, and 94° diagonally. This wide field of view ensures that the camera captures a broad area, making it ideal for both residential and commercial surveillance. This camera supports H.265 video compression, which efficiently reduces bandwidth usage and storage requirements without compromising video quality. It offers a main stream frame rate of 1920 x 1080 at 25 fps and a sub-stream frame rate of 640 x 480 at 25 fps. The Dahua DH-H5AE supports multiple day and night modes, including Auto (ICR), Colour, and B/W, and features digital wide dynamic range (DWDR) for better image quality in challenging lighting conditions. Motion detection with four configurable areas helps identify and alert you to suspicious activity. Audio features include a built-in microphone and speaker, with G.711a audio compression, enabling two-way communication. This functionality is particularly useful for real-time interaction and deterrence. The camera supports alarm events such as no SD card, SD card full, SD card error, network disconnection, motion detection, and audio detection, so you always know the camera's status and any potential issues. Network connectivity is facilitated through an RJ-45 port supporting 10/100 Base-T and Wi-Fi compatibility with IEEE 802.11b/g/n at 2.4 GHz. It also includes storage options with support for microSD cards up to 256 GB, allowing ample space for video recordings. You can manage the camera with DMSS software, and it supports both iOS and Android mobile clients. CE-certified, the Dahua DH-H5AE is built to withstand various environmental conditions, operating in a temperature range of –10 °C to +45 °C (14 °F to 113 °F) and up to 95% humidity. It uses a 5 VDC, 1A power supply, consuming 1.7 W in basic mode and up to 3.5 W during maximum operation. The compact design, measuring φ77.8 mm × 108.1 mm (φ3.06" × 4.26"), and its lightweight build of 204.2 g (0.45 lb) makes it easy to install and position as needed.
