Product Information
Cudy M11000 BE11000 Tri Band Wi-Fi 7 Mesh Router (1 Pack)
- Antenna:6× Fixed Antennas
- Button: WPS Button, Reset Button
- Frequency:6GHz, 5GHz, 2.4GHz
- Power Methods: DC
Product Pricing
EMI Start From*
PRODUCT SPECIFICATIONS
Processor
1.5 GHz Quad-Core CPU
Air Conditioner
Up to 2000 Sq ft
Memory
512 MB (4 Gbit) DDR4
Storage
128 MB (1 Gbit) NAND
Networking & Connectivity
QoS: Per-User Rate Limiting
DHCP:
- Address Reservation
- DHCP Client List
- Server
IPTV/VLAN:
- Bridge
- Tag VLAN
- VoIP VLAN
- IPTV VLAN
TTL Customization:
- Extend
- Spoof
- Custom
IGMP:
- IGMP Proxy
- IGMP Snooping
Forwarding:
- Port Forwarding
- Port Triggering
- UPnP
- DMZ
Firewall:
- SPI Firewall
- DoS Protection
- Block PING
Application Layer Gateway:
- IPSec Passthrough
- L2TP Passthrough
- PPTP Passthrough
- FTP Passthrough
- TFTP Passthrough
- H323 Passthrough
- SIP Passthrough
- RTSP Passthrough
IPv6 Protocols:
- Relay
- Dynamic (SLAAC/DHCPv6)
- Static (Fixed IP)
- Passthrough
- 464XLAT
- MAP-E
- DS-Lite
6 GHz Wi-Fi Speed: 5765 Mbps
5 GHz Wi-Fi Speed: 4324 Mbps (240 MHz)
5 GHz Wi-Fi Speed: 2882 Mbps (160 MHz)
2.4 GHz Wi-Fi Speed: 688 Mbps
6× Fixed Antennas
Wi-Fi Standards: Wi-Fi 7
Max Wi-Fi Modulation: 4K-QAM
Wi-Fi Efficiency: Beamforming
Max Capacity: 384
Recommended Client Upper Limit: 200
Max Wi-Fi Channel Width: 320 MHz
Wi-Fi Security: WPA/WPA2/WPA3
Guest Network: 2.4 GHz, 5 GHz, 6 GHz
WPS: True
6GHz, 5GHz, 2.4GHz
Ethernet Notes: 1× WAN port, the rest are LAN ports
Uplink Ethernet Ports:
1-Pack: 57×56×26 cm
22.44×22.05×10.24 inches
Battery And Power
Power Methods: DC
DC Input: 12V 2A
Power Adapter:
- Input: 100 ~ 240 V, 50/60 Hz AC
- Output: 12V 2A DC
Max Power Consumption (W): 22W
Idle Power Consumption (W): 12W
Ports
Gigabit RJ45 Ports: 3
2.5G RJ45 Ports: 4
Ethernet Notes: 1× WAN port, the rest are LAN ports
Others
WPS Button, Reset Button
ED Control: True
Local Control Method:
- Config Web Page
- App Control
Remote Control Method:
- Config Page via HTTPS
- App Control
- TR069/TR098/TR111/TR143/TR181
Firmware Upgrade:
- Local Update
- App (Over the Air)
- Online Update
Reliability:
- Timed Reboot
- Backup and Restore
Diagnostic Tools:
- Diagnosis
- Ping
- Traceroute
- NSLookup
- System Log
Physical Specification
White
Φ116×202 mm
Φ4.57×7.95 inches
Technical Info
LED: System
Mesh Router
M11000
Warranty Information
1 years
PRODUCT DESCRIPTION
Cudy M11000 BE11000 Mesh Router (1 Pack)
Cudy M11000 BE11000 Tri‑Band Wi‑Fi 7 Mesh Router is built for both wired and wireless versatility, making it ideal for modern homes and offices. It features multiple 2.5 Gbps Ethernet ports, providing high-speed wired connections for gaming consoles, NAS devices, smart TVs, and workstations. These ports ensure reliable performance for bandwidth-intensive tasks and reduce network lag during heavy usage. Its mesh networking technology allows users to expand coverage effortlessly. By adding compatible nodes, you can eliminate dead zones and create seamless roaming across larger areas. Devices automatically connect to the strongest signal as you move through your home or office, ensuring a stable and uninterrupted connection. The router supports multiple nodes, making it scalable for multi-story buildings or large office spaces.
The Cudy App provides easy setup and management. Users can monitor network activity, manage devices, and configure settings directly from their smartphones. Features include parental controls, guest network management, and traffic prioritization to enhance the online experience for every user. The router also supports VPN server and client functionality, giving you secure remote access and enhanced privacy. Security is a key focus. The router uses the latest WPA3 encryption, protecting your network against unauthorized access. You can set up separate guest networks to keep visitors’ devices isolated from your main network. Regular firmware updates through the app ensure your router stays secure and optimized. Whether connecting devices via wired or wireless connections, the Cudy M11000 BE11000 delivers fast, reliable, and secure internet throughout your home or office. Its combination of high-speed ports, advanced mesh technology, and user-friendly app management ensures your network runs smoothly. With robust security and expandable coverage, this router provides a future-ready solution for households and offices that demand speed, stability, and ease of use.
FAQ
How many devices can it handle?
It supports dozens of devices simultaneously.
Does it support mesh networking?
Yes, it allows you to add nodes to expand coverage.
What kind of processor does it have?
A 1.5 GHz Qualcomm quad-core processor.
Does it have Ethernet ports?
Yes, multiple 2.5 Gbps Ethernet ports for wired connections.
