Cooler Master MasterBox NR200 Case
|
FAN SUPPORT
| PRE-INSTALLED FANS - TOP 1x 120mm 650-1800RPM PWM (SickleFlow) PRE-INSTALLED FANS - FRONT N/A PRE-INSTALLED FANS - REAR 1x 92mm 650-2300RPM PWM (SickleFlow) PRE-INSTALLED FANS - BOTTOM N/A FAN SUPPORT - TOP 2x 120mm FAN SUPPORT - REAR 1x 92mm FAN SUPPORT - BOTTOM 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots) FAN SUPPORT - SIDE 2x 120/140mm |
RADIATOR SUPPORT
| RADIATOR SUPPORT - TOP N/A RADIATOR SUPPORT - REAR 92mm (not compatible with vertical GPU installation) RADIATOR SUPPORT - BOTTOM 120mm, 240mm, (recommended for custom loops only) RADIATOR SUPPORT - SIDE 120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation) |
CLEARANCE
| CLEARANCE - CPU COOLER 155mm, 76mm (GPU in vertical position) CLEARANCE - PSU 130mm CLEARANCE - GFX L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot) DUST FILTERS Top, Bottom, Left side, Right side |
Others
| SERIES MasterBox Series SIZE Mini ITX AVAILABLE COLOR(S) Black, MATERIALS Steel, Plastic, Mesh DIMENSIONS (L X W X H) 376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions VOLUME (EXLC. PROTRUSIONS) 18.25L MOTHERBOARD SUPPORT Mini DTX, Mini ITX, Max. size: 244 x 226mm EXPANSION SLOTS 3 POWER SUPPLY SUPPORT SFX, SFX-L I/O PANEL 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic) |
DRIVE BAYS
| 5.25" DRIVE BAYS 0 3.5" DRIVE BAYS 1 (Max. 2) 2.5" / 3.5" DRIVE BAYS (COMBO) 1 2.5" DRIVE BAYS 2 (Max. 3) |
Cooler Master MasterBox NR200 Case
The Cooler Master MasterBox NR 200 Mini-ITX Case. Cooler Master offers an alternative to large computer cases by maintaining popular features such as accessibility, customization, and ventilation while saving you precious space. Mini-DTX and Mini-ITX motherboard support up to 9.6 x 8.8" gives you plenty of options when choosing small-scale components. The removable steel frame panels give you complete 360-degree accessibility, allowing you to take advantage of every inch of this case. The multiple 2.5 and 3.5" drive bays can be configured to fit an array of solid state and hard disk drives. Triple-slot graphics cards up to 12.99" length can fit within the MasterBox while providing ample room for liquid cooling systems. Airflow is prioritized with one 92mm rear fan and one 120mm top fan preinstalled in the case. Two USB 3.2 Gen 1 Type-A ports rest at the top of the chassis along with a 3.5mm headset jack, granting easy access for peripheral connectivity.
360 Degree Accessibility
Easily dismantle every panel and frame part of the NR200, providing you easy access to the inside of the chassis. Frame parts are held in with screws and can be removed, giving you multiple angles while you build.
Big Case in Less Space
The MasterBox NR200 takes all the features found in large chassis cases and packs them in a smaller package. Multiple fan mounts and open ventilation produces maximum airflow while offering ample room for water-cooling, air-cooling, and triple-slot graphics card clearances.
Tool-Free Access
Gain quick access to each piece of this steel case without tools. External panels and top mounted fans utilize pins for easy removal.
Multiple Build Options
Multiple mounting locations allows you to utilize liquid cooling along the side and bottom of the compact enclosure. Power supply units with a maximum size of 9.6 x 8.8" can be front mounted providing you with extra motherboard clearance. Up to 7 fans can be accommodated, adding additional ventilation options and keeping your system cool.
Flexible Hard Drive Array
Multiple drive bays allow you to connect an array of multiple hard drives. The combo bay allows you to store up to three 2.5" solid state drives, or two 3.5" hard disk drives. You may even mix and match between solid state and hard disk drives depending on your configuration.
Customization
Cooler Master give owners freedom of customization by allowing the installation of additional fans, interchangeable side panels, and even providing plans so you can 3D print a series of feet for your case.
