CANON IMAGEPROGRAF TZ-5300 LARGE FORMAT PRINTER
- Brand: Canon
- Memory: Standard: 128 GB; Physical: 2 GB
- Dimensions: Main Unit 1548 x 762
Product Pricing
EMI Start From*
SPECIFICATIONS
SG Raster (Swift Graphic Raster)
HP-GL/2
HP RTL
PDF (Ver. 1.7)
JPEG (Ver. JFIF1.02)
Print Speed
Plain Paper
CAD Drawings, A0
26 sec [Fast (Custom Q5)]
35 sec [Fast]
1 min 6 sec [Standard]
Poster, A0
29 sec [Fast (Custom Q5)]
41 sec [Fast]
1 min 15 sec [Standard]
Heavyweight Coated Paper HG
Poster, A0
2 min 34 sec [Standard]
Glossy Photo Paper HG 170
Poster, A0
5 min 15 sec [Standard]
Roll Paper
Two Roll, Front Load, Front Output / Top Output
Cut Sheet
Front Load, Front Output*3
Media Width (Roll / Cut Sheet)
203.2 ~ 917 mm
Min. Printable Length
Roll Paper
Front Output: 203.2 mm, Top Output: 205 mm
Cut Sheet
203.2 mm
Min. Printable Length
Roll Paper
18 m*4
Cut Sheet
610 mm
Maximum Outer Roll Diameter
175 mm or less
Borderless Printing Width
(Roll paper only)
203.2 ~ 917 mm
Margins (Recommended Area)
Roll Paper
Top: 20 mm, Bottom: 3 mm, Side: 3 mm
Cut Sheet (Apple AirPrint)
Top: 20 mm, Bottom: 31 mm, Side: 3 mm
Cut Sheet (Others)
Top: 20 mm, Bottom: 20 mm, Side: 3 mm
Margins (Printable Area)
Roll Paper
Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll Paper (Borderless Print)
Top: 0 mm, Bottom: 0 mm, Side: 0 mm
Cut Sheet (Apple AirPrint)
Top: 3 mm, Bottom: 12.7 mm, Side: 3 mm
Cut Sheet (Others)
Top: 3 mm, Bottom: 20 mm, Side: 3 mm
5 pl
Ink Capacity
Sales Ink: 330 ml / 700 ml (MBK, BK, C, M, Y)
Bundled Starter Ink: 330 ml (MBK) / 160 ml (BK, C, M, Y)
Ink Type
Pigment Ink
Memory
Physical: 2 GB
Networking & Connectivity
USB Memory (Direct Print)
USB B Port (Series B, 4 pins):
Hi-Speed USB
Full Speed (12 Mbit/sec)
High Speed (480 Mbit/sec)
Bulk Transfer
Gigabit Ethernet:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX/Auto-Negotiation
IEEE 802.3ab 1000base-T/Auto-Negotiation
IEEE 802.3x Full Duplex
SNMP, HTTP, FTP, TCP/IP (IPv4/IPv6)
Wireless LAN:
IEEE802.11b/g/n
WEP (64/128bit)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)
Battery And Power
AC 100 - 240 V, 50 - 60 Hz
Power Consumption
Printing*6
157 W or less
Sleep Mode*6
2.0 W or less
Power Off
0.3 W or less
Others
5-Colour 36" (914 mm)
Number of Nozzles
15,360 nozzles (MBK: 5,120 nozzles; BK, C, M, Y: 2,560 nozzles each)
Nozzle Pitch
1200 dpi (2 lines)
Line Accuracy
± 0.1% or less
Hard Disk
500 GB (Encrypted)
Physical Specification
1548 x 762 x 1126 mm (Basket Closed)
Main Unit + Paper Output Support + Top Output Guide
1548 x 1293 x 1189 mm (Basket Open)
1548 x 960 x 1189 mm (Basket Closed)
206 kg
Main Unit + Paper Output Support + Top Output Guide
207 kg
Technical Info
Warranty Information
DESCRIPTION
CANON IMAGEPROGRAF TZ-5300 LARGE FORMAT PRINTER IN BANGLADESH
Features
- Accounting Manager - Track ink and media usage for cost calculation and reporting.
- Media Configuration Tool - Easily manage, update, and arrange media information in the printer's operation panel and printer driver.
- Device Management Console - Effectively manages multiple printers and monitors activities such as error messages and printer information for up to 50 printers.
- Quick Utility Toolbox - Quick access to supporting utilities and settings. From printer information, speed dial, and destination folder settings to scanning and cloud sharing.
- Direct Print & Share - Batch printing, job presets, shortcut prints, and cloud printing can be managed quickly and efficiently.
- Free Layout Plus - Enjoy nesting, tiling, and duplex printing features.
- AutoCAD® Optimised Printer Driver - Optimised printer driver for optimal printing control and enables faithful printing of drawing data created with AutoCAD®.
- Easy-PhotoPrint Editor - Edit, trim, and rotate your images into unique layouts and designs, including posters, calendars, collages, and more. Available on iOS, and Android OS.
- Apple AirPrint - Print PDF files wirelessly via mobile app for Apple iPad® and iPhone®.
- Canon Print Service - Direct document and photo printing via mobile app from Android devices without the need to download any printer-specific applications.
- Canon PRINT Inkjet/SELPHY - Print PDF files wirelessly via mobile app for Android tablets and smartphones.
Fast Print Speed
Twin-carriage motors ensure maximum productivity on the TZ series. With print data processing, pre-print operation and print spooling optimised, the TZ series realised fast throughput during continuous printing (up to 4 pages per minute for A1 sheets) and fast first print from standby or sleep mode (as fast as 19 seconds).
Productivity At Its Peak
The dual-roll feeding unit enables users to load up to two rolls of media, reducing the need to switch between media types or sizes in high-volume printing. The top delivery tray supports stacking of up to 100 A0-size sheets, while hot-swap replacement allows empty ink tanks and media roll to be replaced while the printer continues to print, maximising productivity.
Simplified Media Handling
Automatic media loading and automatic media type detection simplified the media loading and replacement workflow to just one step, which is to "simply place the roll and slide" into the printer. Roll paper indicator allows user to check from a distance if a roll is loaded, the approximate remaining media amount, and time to switch the roll. The remaining roll amount is displayed on the operation panel, and an alert will be sent out when the media is not sufficient to complete the print job.
Borderless Printing
Borderless printing on standard and custom sizes for all supported media. With additional features such as three-sided edge-to-edge printing, the TZ series can handle any poster printing task with ease.
Unparalleled Security
Print jobs and data are encrypted and transmitted through a secure protocol throughout the print process. Secure file and disk erasure, user access restriction, and printer functionality restriction further prevent information leaks and other security risks, resulting in unparalleled security.
LUCIA TD Ink
5-colour LUCIA TD pigment ink is formulated to produce sharp text, accurate lines, and vivid colours with excellent weather resistance, even on plain paper.
FINE Print Head
Equipped with micron-sized nozzles, the fully integrated print head provides superb uniformity of ink density and colours, while multi-pass printing ensures the highest print quality is maintained on every print.
L-COA PRO Image Processing Engine
L-COA PRO imaging processor is capable of processing massive image data, drives high printing speed while maintaining supreme print quality, enabling fast first printout time and continuous printing speed.
High Precision Mechanical Platform
The unibody structure is engineered to provide a strong and stable platform, maintaining a precise distance between print head and media, virtually eliminating oscillation for high-precision ink placement with minimal inter-colour discrepancy.
Non-Firing Detection and Compensation System
Equipped with an in-built sensor, the non-firing detection and compensation system checks the ink ejection from print head nozzles, and when a blockage is detected, another nozzle automatically provides backup. This prevents banding and reduces the frequency of print head cleaning required. The Canon imagePROGRAF TZ-5300 Printer offers precise, high-resolution, large-format printing with reliable performance. Ideal for offices, design studios, and professionals seeking efficient, premium-quality printing at the best printer price in Bangladesh.
