Printer Type
| 5-Colour, 36" / 914 mm
|
Number of Nozzles
| 15 360 nozzles (MBK*: 5 120 nozzles; BK*, C*, M*, Y* 2 560 Nozzles each
|
Print Resolution
| 2400 x 1200 dpi
|
Nozzle Pitch
| 1200 dpi (2 lines)
|
Line Accuracy
| ±0.1% or less
|
Minimum Ink Droplet Size
| 5 pi
|
Ink Capacity
| Sales Ink: 130ml/300ml (MBK*, BK*,C*,M*, Y*) Bundled Starter Ink: 130ml (MBK*) / 90ml (BK*,C*,M*, Y*)
|
Ink Type
| Pigment ink: Matte Black, Black, Cyan, Magenta, Yellow
|
Printer Language
| SG Raster (Swift Graphic Raster) HP-GL/2 HP RTL JPEG (Ver. JFIF 1.02)
|
Standard Interfaces (Built-in)
| USB B Port: Built-in (Hi-Speed USB ), Full-Speed (12Mbps), High Speed (480Mbps), Bulk transfer, Series B (4 pins) GB Ethernet: IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto-Negotiation, IEEE 802.3ab 1000base-T/ Auto-Negotiation, IEEE 802.3x Full-Duplex Wireless LAN: IEEE802.11n/g/b
|
Memory
| Standard memory: 2GB
|
Hard Disk
| N/A
|
Plain Printing Speed
|
|
CAD Drawing - Plain Paper (A0)
| 40 sec (Fast Economy Mode)
48 sec (Fast)
1 min 14 sec (Standard)
|
CAD Drawing - Heavyweight Coated Paper HG (A0)
| 47 sec (Fast Economy Mode)
1 min 11 sec (Fast)
2 min 18 sec (Standard)
|
Poster - Plain Paper (A0)
| 44 sec (Fast Economy Mode)
44 sec (Fast)
1 min 18 sec (Standard) |
Poster - Heavyweight Coated Paper HG (A0)
| 1 min 41 sec (Fast)
2 min 36 sec (Standard)
|
Media Handling
|
|
Media Feed Method
| Roll Paper: One Roll, Upper Load Front Output
Cut Sheet: Upper Load Front Output (Manual feed using media locking lever)
|
Media Output (SD-23)
| Standard Position: 1 Sheet
Folding Position: 20 sheets on A1 portrait/A0 portrait
Flat Position: 20 sheets on A1 landscape/A2 landscape |
Media Width (Roll / Cut Sheet)
| 203.2 - 917 mm
|
Media Thickness Media Width (Roll / Cut Sheet)
| 0.07 - 0.8 mm
|
Min. Printable Length
| Roll Paper: 203.2mm Cut Sheet: 279.4mm |
Maximum Printable Length
| Roll Paper: 18.0m (Varies according to the OS and application) Cut Sheet: 1.6m |
Maximum Media Roll Outer Diameter
| 150mm or less
|
Borderless Printing Width (Roll Only)
| [Recommended]
515.0mm(JIS B2),594.0mm(ISO A1), 254.0mm (10.0in),355.6mm (14.0in),431.8mm (17.0in),609.6mm (24.0in)
[Printable]
257.0mm(JIS B4),297.0mm(ISO A3),329.0mm(ISO A3+),420.0mm(ISO A2),203.2mm (8.0in),304.8mm (12.0in),406.4mm(16.0in),508.0mm (20.0in),300.0mm,500.0mm,600.0mm |
Dimensions And Weight
|
|
Physical Dimensions And Weight
| Main Unit + Stand + Basket (SD-32)
Approx. 1289 x 887 x 1060 mm (Basket Open)
Approx. 1289 x 757 x 1060 mm (Basket Closed)
Approx. 60 kg
|
Packaged Dimensions And Weight
| Main Unit + Stand + Pallet:
Approx. 1462 x 913 x 961 mm
Approx. 105 kg
|
Power And Operating Requirements
|
|
Power Supply
| AC 100 - 240 V, 50 - 60 Hz
|
Power Consumption
| Operation: 69W or less
Sleep Mode: 3.6W or less
Power Off: 0.3W or less
|
Operating Environment
| Temperature: 15°C - 30°C
Humidity: 10% - 80% RH (no dew condensation)
|
Acoustic Sound
| [Acoustic Pressure]
Operation: 44 dB(A)
(Plain Paper, Line Drawing; Print Priority - Standard)
Standby : 35 dB(A) or less
[Acoustic Power]
Operation : 60 dB
(Plain Paper, Line Drawing; Print Priority - Standard)
|
Accessory
|
|
2"/3" Roll Holder (Optional)
| RH2-35
|
Scanner
|
|
Scan Technology
| SingleSensor with multiple LED illumination
|
Maintenance Cartridge
| MC-30
|
Optical Resolution
| 600dpi
|
Scan Width
| 36" / 914 mm
|
Minimum scan width
| 6" / 150 mm
|
Maximum scan length
| 109" / 2768 mm
|
Document thickness
| Minimum 0.07mm
Maximum 0.5mm
|
Max Scan Speed (mm/s)
| [COPY]
Draft (300/300 dpi): 1 ips (col), 3 ips (mono)
Standard (300/600 dpi): 1 ips (col), 3 ips (mono)
Best (600/600 dpi): 0.5 ips (col), 1.5 ips (mono)
[SCAN]
Draft (200 dpi): 1 ips (col), 3 ips (mono)
Standard (300 dpi) : 0.5 ips (col), 1.5 ips (mono)
Best (600 dpi) : 0.33 ips (col), 1 ips (mono)/td> |
PC And Software Included
| ScanApp Lei Software
|
Functions
| Scan to USB: RGB/Greyscale/BW, TIFF
(No ScanApp Lei)
Scan to USB: RGB/Greyscale/BW, JPG, PDF, PDF/A, M-PDF (ScanApp Lei available)
Scan to PC: RGB/Greyscale/BW, Tiff, JPEG, PDF, PDF/A, TiffG4, M-PDF
Copy: RGB/Greyscale/BW
Copy And Save: Copy and scan to PC concurrently
|
