BDCOM GP3600-08 8 Port GPON OLT Network Switch
BDCOM GP3600-08 8 Port GPON OLT Network Switch-cover-thumbnail

BDCOM GP3600-08 8 Port GPON OLT Network Switch

Stock : In Stock
PID : P4082506003
Brand : V-SOL
Model : GP3600-08
Warranty : 1 Year
★ ★ ★ ★ ★
0 Reviews

Product Pricing

Discount Price

৳ 134,500 ৳ 139,500
Available Payment Method

EMI Start From*

৳ 4,736

BDCOM GP3600-08 Specification

Standards
  • · ITU-T G.984/G.988
  • · IEEE 802.11D, Spanning Tree
  • · IEEE 802.1Q, VLAN
  • · IEEE 802.1w, RSTP
  • · IEEE 802.3ad physical link
  • static/dynamic aggregation
  • (LACP), Ethernet - II
VLAN
  • . Port/IP/Protocol/MAC-based
  • VLAN
  • · 4K VLAN
  • · QinQ and flexible QinQ
Multicast:
  • . L2 multicast
  • · IGMP snooping
  • · MLD snooping
  • · Fast-leave
Layer 3 Function
  • . Static route
  • · RIPv1/v2
  • · OSPF
  • · BGP
QoS
  • · Backpressure flow control (half duplex)
  • · IEEE 802.3x flow control (full duplex)
  • · IEEE 802.1p, CoS
  • · WRR, SP and FIFO queue schedule
  • · Limiting the uplink/downlink rate based
  • on each ONU
  • · DBA and SLA
Reliability
  • · Unidirectional Link Detection (UDLD)
  • · Hot swap of the GPON optical module
  • · Optical path protection of GPON (type
  • B/C, hand-in-hand)
  • · Abnormal luminescence ONU detection
  •  such as long luminescence
  • · IEEE 802.3ad LACP
DHCP Function
  • . Server/Relay/Client
  • · DHCP snooping
  • · DHCP option 66,67,82
  • · DAI
  • · IP source guard
Network Security
  • . L2~4 ACL
  • · Flow-based ACL
  • · MAC limitation
  • · MAC sticky
  • · Port isolation
  • · Packet storm control
  • · Transmission data
  • encryption on the PON
  • interface
  • · Anti attack for DDOS, TCP-
  •  SYN-flood, UDP-flood, ARP-
  •  flood, etc.
Management
  • . Various management modes
  • such as CLI, Telnet, SSH,
  • HTTP, SSL and SNMP
  • · ISSU
  • · FTP/TFTP
  • · SPAN/RSPAN
  • · NTP
Network Availability
  • . STP/RSTP/MSTP
  • · BPDU guard
  • · EAPS

BDCOM GP3600-08 8 Port GPON OLT Network Switch in Bangladesh

BDCOM GP3600 Series complies with ITU-T G.984/G.988 and meets requirements about GPON OLT in Network Access Technical Requirements. It fully supports CTC2.0, automatic discovery and cooperation with ONUs of different manufacturers. BDCOM GP3600 Series supports the Asymmetric uplink 1.25Gbps/ downlink 2.5Gbps PON transmission rate, efficient bandwidth usage and Ethernet services, helping carriers to provide reliable services to their users. Its coupling ratio ups to 1:128, and its support of different hybrid ONU networks minimize the carrier's investment. BDCOM GP3600 Series supports routing functions such as RIP,OSPF and BGP. BDCOM GP3600 Series ,based on the edge-cutting technologies, is strong in functions and QoS guarantee, SLA and DBA can be easily listed out.

GPON: Abiding by ITU-T G.984/G.988, BDCOM GP3600 Series OLT meets relevant requirements of GPON OLT regulated in Network Access Technical Requirements and China Telecom GPON Technical Requirements CTC2.0;

System Capacity: GP3600 Series supports 4/8/16 GPON ports.

Uplink Interface: GP3600 Series is equipped with maximum 4 GE SFP ports, 4 GE combo ports and 4 10GE SFP+ ports.

Dimensions: 1U, occupies a small space.

Environmental Protection: low power consumption and low operating cost.

Bus Optical Fiber Protection: the link can be automatically switched when trouble occurs in the optical fiber;
Power Characteristics: supports dual-AC, dual-DC and AC/DC power supply. The power supply supports modularized design, hotswap and EMC-3 standard. It well adapts to the environment.

What is the BDCOM GP3600-08 8 Port GPON OLT Network Switch Price in Bangladesh 2025 ?

The V-SOL GP3600-08 Price in BD is 134,500৳ . This BDCOM GP3600-08 8 Port GPON OLT Network Switch Manufacturing by V-SOL Comes With 1 Year Warranty & Based on 0 reviews. Tech Land BD Offers you V-SOL GP3600-08 by 134,500৳ and its regular price is 139,500৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
