HORED AI106G 6-PORT GIGABIT AI POE SWITCH
- Bandwidth: 12Gbps(no block)
- Transfer Rate: 1000Mbpsfull Duplex
- POE pin: 1/2(+)，3/6(-)
- Operating Temperature: 0°~40°C
SPECIFICATIONS
Networking & Connectivity
IEEE802.3at,,IEEE802.3ab
Battery And Power
External power adapter: 60W
Ports
2 10/100/1000Mbps RJ45 port uplink(Port5~port 6)
Others
Safety regulation: CE/ROHS/FCC/CCC
AI Smart POE Switch, 4* 1000Mbps RJ45 port( POE is available), 2* 1000Mbps Uplink.
5 working modes:
Standard switching mode: All ports communicate freely;
AI VLAN: Avoid the internet storm and enhance the network ability;
AI Extend: Extend 250M transmission;
AI PoE: Automatic self checking, reboot the device while find it fake dead;
AI QoS，Video data first, more fluent transmission
Physical Specification
Operating Humidity：10%~90%，Non-condensing
Technical Info
RESV
LINK/ACT
Frame filtering and transmission rate:
10M port maximum 14,880pps
100M port maximum 148,810pps
1000Mport maximum 1，488，100pps
Warranty Information
DESCRIPTION
HORED AI106G 6-PORT GIGABIT AI POE SWITCH
The HORED AI106G is a 6-port gigabit PoE switch that enables data transfer at a maximum rate of 1000Mbps full duplex. The switch has 4 10/100/1000Mbps PoE RJ45 ports (Port 1~ Port4) and 2 10/100/1000Mbps RJ45 uplink ports (Port5~port 6). It complies with various network protocols and standards such as IEEE802.3i, IEEE802.3u, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3ab, making it compatible with different devices. With a bandwidth of 12Gbps (no block), it offers reliable performance for organizations with high data demands. The LED indicators display power, RESV, LINK/ACT, and POE pin 1/2 (+), 3/6 (-). The switch provides maximum power of 30W for a single port and operates using an external adapter with a maximum capacity of 60W. Its dimensions are 125mm x 75mm x 27mm, and it weighs 0.5kg. This switch is compliant with CE/ROHS/FCC/CCC safety regulations and comes with a 1-year replacement warranty. The operating temperature range of the switch is 0°~40°C, and it can operate in humidity levels ranging from 10% to 90%, non-condensing. Bangladesh's top retailer of computer hardware and applications is Techland BD. A hallmark of Techland BD is its top-notch client support. They have a helpful and knowledgeable crew that is always willing to help customers. The large selection of Hored Switch available at Techland BD is well recognized. The large selection of Switch available at Techland BD is well recognized.
