Coolermaster ELITE 500 ATX Mid Tower Case Overview
Size
| Mid Tower
|
Color
| Black
|
Materials
| Steel, Plastic, Tempered Glass
|
Motherboard Support
| Mini ITX, Micro ATX, ATX
|
Expansion Slots
| 7 |
Drive Bays
| 5.25" Drive Bays 0 (E500-KGNN-S00, E500-KNNN-S00), 1 (E500-KG5N-S00, E500-KN5N-S00) 2.5" / 3.5" Drive Bays (combo) 2 2.5" Drive Bays 3 (E500-KGNN-S00, E500-KNNN-S00), 5 (E500-KG5N-S00, E500-KN5N-S00)
|
I/O Panel
| 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
|
Pre-installed Fans
| Rear 1x 120mm Top 2x 120mm, 2x 140mm Front 2x 140mm, 3x 120mm (E500-KGNN-S00, E500-KNNN-S00), 2x 120mm (E500-KGNN-S00, E500-KNNN-S00), 3x 120mm (remove ODD bracket) (E500-KGNN-S00, E500-KNNN-S00) Rear 1x 120mm
|
Radiator Support
| Top 120 / 240mm (32mm max motherboard component height) Front 120mm, 140mm, 240mm, 280mm, 360mm (Remove ODD) (E500-KG5N-S00, E500-KN5N-S00) Rear 120mm
|
Clearance
| CPU Cooler TG: 161mm, Steel: 163mm PSU 160mm (E500-KGNN-S00, E500-KNNN-S00), 180mm (E500-KG5N-S00, E500-KN5N-S00) GFX 350mm (w/o front fans & radiator) (E500-KGNN-S00, E500-KNNN-S00), 400mm (w/o front fans & radiator) (E500-KG5N-S00, E500-KN5N-S00)
|
Cable Routing
| 18.5mm
|
Dust Filters
| Front, Top, Bottom
|
Power Supply Support
| Bottom Mount, ATX
|
Volume
| 37.29L (E500-KGNN-S00, E500-KNNN-S00) (exlc. Protrusions), 42.40L (E500-KG5N-S00, E500-KN5N-S00) (exlc. Protrusions)
|
Dimensions
| 409 x 204 x 455mm
|
Coolermaster ELITE 500 ATX Mid Tower Case in Bangladesh
The Elite 500 is the essential solution for optimized cooling. Substantial ventilation on the front panel allows fresh air into the system for both air-cooled and liquid cooled configurations.
For simple tasks, the Elite 500 is a cost-effective solution to professional computing. For higher-demand tasks, the Elite 500 boasts a high compatibility for upgrades, able to house liquid cooling and provides clearance for the longest, widest graphics cards.
LARGE FILTERED INTAKES
The front panel is constructed with a substantially large, unrestricted intake grill to provide superb airflow to the system.
WITH/WITHOUT ODD SUPPORT
Depending on preference, an ODD version of the chassis is available. If an ODD is not preferred, a cleaner appearance and more cooling options on the top and front panels are supported. The ODD version of the Elite 500 is slightly deeper in comparison to its non-ODD counterpart.
VERSATILE COOLING OPTIONS
Support for up to six fans and front, top, and rear radiator support ensure that performance is not compromised.
FULL BLACK COATING & PSU COVER
Let your system stand out with an all-black background and a PSU cover to hide cables.
BREATHABLE POWER SUPPLY SHROUD
The PSU cover is ventilated on top of the power supply location, this allows actively cooled units to be installed either with the fan facing the top or bottom, also with the possibility of installing passively cooled power supplies.
ROOM FOR UPGRADES
Support for up to a 350mm graphics card (400mm in the ODD version), a 161mm CPU cooler, and multiple fans/radiators locations provides room for upgrades to stay ahead of the game.
TG / STEEL LEFT SIDE PANEL OPTION
Elite 500 and Elite 500 ODD offer side panel options to satisfy various aesthetic tastes. Edge-to-edge tempered glass side panel versions offer the opportunity to boldly showcase unique setups, while steel side panel versions are also available for those who prefer a stealthy minimalist look.
HEADSET JACK
The single 4 pole headset jack features both Audio and Microphone capabilities simultaneously so that separate jacks are not needed.
VERSATILE HDD CAGE
The HDD cage is (re)movable. The cage can be shifted forward to make room for a longer PSU, backwards for additional radiator space, or completely removed if HDD storage is not needed.
